1268 / 1410
1268
Prices in EURO - VAT not included
1268
DIE HOLDERS
13
9465G
Orig. Völkel - Art. 150
DIN 225 (DIN EN 22568). High-resistance die cast. Body with finely worked seat, lacquered. With
adjusting and fixing screws.
Extra quality.
Ø and thickness
mm
16x5 20x5 20x7 25x9 30x11 38x10 38x14
9465G
Each 3,84
4,00
4,00
4,56
7,40 11,60 11,60
Ø and thickness
mm
45x14 45x18 55x16 55x22 65x18 65x25
9465G
Each 14,10 14,10 18,10 18,10 30,50 30,50
vuoto
DIEHOLDERS
9467G
Orig. Völkel - Art. 152
DIN 225 (DIN EN 22568). High-resistance steel. Body with finely worked seat, lacquered with
polished bars. With adjusting and fixing screws.
Extra quality.
Ø and thickness
mm
45x18 55x22 65x25 75x20 75x30 90x22 90x36
9467G
Each 23,10 32,90 41,20 69,10 69,10 85,50 85,50
Ø and thickness
mm
105x22 105x36
9467G
Each 131,00 131,00
vuoto
DIEHOLDERS
PIPE DIE HOLDERS
9468
9469
9470
Prod. SCU
Made of steel.
Both ends are arranged for mounting of two round dies with different diameter.
Art......................................
9468
9469
9470
For dyes Ø
mm 20,6x25,4 25,4x38,1 38,1x50,8
Each 30,20
40,40
51,10
vuoto
PIPEDIEHOLDERS
ADJUSTABLE TAP WRENCHES
9472
Prod. SCU
Painted body with levers.
Hardened clamping wedges.
In high-resistance steel. Fine quality.
Size
0
1
2
3
4
For taps by Withworth
inch 1/16 to 1/4 1/16 to 3/8 1/32 to 1/2 7/32 to 3/4 7/16 to 1
For taps by
M.
1 to 8
1 to 10
4 to 12
5 to 20
9 to 27
Drive framework opening mm 2,1 to 4,9 2,1 to 5,5 3,4 to 9 4,9 to 12 5,5 to 16
9472
Each 16,40
16,40
23,60
33,80
45,40
Size
5
6
7
For taps by Withworth
inch 1/2 to 1 1/4 3/4 to 1 1/2 1-2 1/2
For taps by
M.
13 to 33 19 to 39 27 to 64
Drive framework opening mm 7 to 20 11 to 24 16 to 40
9472
Each 59,10
92,50
92,50
vuoto
ADJUSTABLETAPWRENCHES
9476G
Orig. Völkel - Art. 130
DIN 1814. High-resistance die cast. Lacquered body with polished levers.
Hardened and ground clamping wedges. Extra quality.
Size
0
1
1 1/2
2
3
For taps by Withworth
inch 1/16 to 1/4 1/16 to 3/8 1/16 to 1/2 5/32 to 1/2 7/32 to 3/4
For taps by
M.
1 to 8
1 to 10
1 to 12
4 to 12
5 to 20
Drive framework opening mm 2 to 5
2 to 6,3 2,1 to 8
3 to 9
4,9 to 12
9476G
Each 4,84
5,28
5,28
8,54
16,10
Size
4
5
For taps by Withworth
inch 7/16 to 1 1/2 to 1 1/4
For taps by
M.
11 to 27 13 to 32
Drive framework opening mm 5,5 to 16 7 to 20
9476G
Each 29,70
45,60
vuoto
ADJUSTABLETAPWRENCHES
9478G
Orig. Völkel - Art. 140
DIN 1814. High-resistance die cast. Lacquered body with polished levers.
Hardened and ground clamping wedges. Extra quality.
Size
0
1
1 1/2
2
3
For taps by Withworth
inch 1/16 to 1/4 1/16 to 3/8 1/16 to 1/2 5/32 to 1/2 7/32 to 3/4
For taps by
M.
1 to 8
1 to 10
1 to 12
4 to 12
5 to 20
Drive framework opening mm 2 to 5
2 to 6,3 2,1 to 8
3 to 9
4,9 to 12
9478G
Each 7,12
8,12
8,12
14,40
22,80
Size
4
5
6
7
For taps by Withworth
inch 7/16 to 1 1/2 to 1 1/4 3/4 to 1 1/2 1 to 2.1/8
For taps by
M.
11 to 27 13 to 32 18 to 42 25 to 52
Drive framework opening mm 5,5 to 16 7 to 20 11 to 24 16 to 32
9478G
Each 42,80
67,10
78,40
129,00
vuoto
ADJUSTABLETAPWRENCHES
