1264 / 1410
1264
Prices in EURO - VAT not included
1264
CHROME STEEL TAPS AND DIES
13
9430
M
ROUND DIES – CHROME steel. RIGHT-HAND USE.
M Coarse Metric Thread.
Type
2
3
4
5
6
7
8
For threads
mm 2
3
4
5
6
7
8
Pitch
mm 0,4
0,5
0,7
0,8
1
1
1,25
Threading die Ø
mm 25,4
25,4
25,4
25,4
25,4
25,4
25,4
9430
Each 8,78
6,32
6,32
5,32
5,32
5,48
5,32
Type
8A
9
10
10A 11
12
14
For threads
mm 8
9
10
10
11
12
14
Pitch
mm 1,25
1,25
1,5
1,5
1,5
1,75
2
Threading die Ø
mm 38,1
25,4
25,4
38,1
38,1
38,1
38,1
9430
Each 7,56
5,40
5,32
7,64
8,78
7,56
7,56
Type
16
16A 18
20
For threads
mm 16
16
18
20
Pitch
mm 2
2
2,5
2,5
Threading die Ø
mm 38,1
50,8
50,8
50,8
9430
Each 7,56 14,40 14,40 14,80
CHROMESTEELTAPSANDDIES
9432
MF
Product description as Art. 9430
MF Fine Metric Thread.
For threads
mm
6
8
10
10
12
12
14
Pitch
mm
0,75
1
1
1,25
1,25
1,5
1,25
Threading die Ø
mm 25,4
25,4
38,1
38,1
38,1
38,1
38,1
9432
Each 7,12
7,12 10,70 10,70 10,80 10,80 10,80
For threads
mm
14
16
18
20
Pitch
mm
1,5
1,5
1,5
1,5
Threading die Ø
mm 38,1
38,1
38,1
50,8
9432
Each 10,80 10,80 10,80 21,40
CHROMESTEELTAPSANDDIES
9436
GAS
Product description as Art. 9430
Cylindrical GAS Thread for threading pipes.
For threads
inch
1/8
1/4
3/8
1/2
3/4
1
Threads per inch
Nr
28
19
19
14
14
11
Threading die Ø
mm 38,1
38,1
38,1
50,8
50,8
63,5
9436
Each 8,60
8,60
8,60 18,10 18,10 37,10
vuoto
CHROMESTEELTAPSANDDIES
9440
M
NUT SCREWS IN WOODEN BOX
The set contains:
CHROME taps, 1 pc for each size - Art. 9410 3-4-5-6-8-10-12mm
CHROME dies, 1 pc for each size - Art. 9430 type 3-4-5-6-8-10-12
1 extensible tap wrench Size 1.1/2
1 die-holder Ø 25.4mm
9440
Each 230,00
vuoto
CHROMESTEELTAPSANDDIES
9448
M
Product description as Art. 9440
The set contains: br>CHROME taps, 1 series for each size - Art. 9410 3-4-5-6-8-10-12-14-16-
18mm
CHROME dies, 1 pc for each size - Art. 9430 type 3-4-5-6-8-10A-12-14-16-18
Extensible tap wrenches Size 1 and 3, 1pc for each size.
Die-holder, 1 pc for each size Ø 25.4 and 38.1mm.
9448
Each 375,00
vuoto
CHROMESTEELTAPSANDDIES
9455
M MF
Product description as Art. 9440
The set contains:
CHROME taps, 1 series for each size - Art. 9412 2-3-4-5-6-7-8-10-12-14-16mm
CHROME taps, 1 series for each size - Art. 9416 8x1 - 10x1 - 10x1.25 - 12x1.25 - 12x1.5 -
14x1.25 - 14x1.5 - 16x1.5 – 18x1.5mm
CHROME dies, 1 pc for each size - Art. 9430 type 2-3-4-5-6-7-8-10A-12-14-16
1 CHROME dies, 1 pc for each size - Art. 9432 8x1 - 10x1 - 10x1.25 - 12x1.25 - 12x1.5 - 14x1.25
- 14x1.5 - 16x1.5 – 18x1.5mm
Extensible tap wrench Size 1 and 3, 1 pc for each size.
1 pc “T" tap wrench – Size 1
Die-holder, 1 pc for each size Ø 25.4 e 38.1mm.
9455
Each 415,00
CHROMESTEELTAPSANDDIES
