1265 / 1410
1265
Prices in EURO - VAT not included
1265
CHROME STEEL TAPS AND DIES
13
9456
new
M MF
Product description as Art. 9440
Content:
1 series CHROME taps Art. 9412 mm 2-3-4-5-6-7-8-9-10-11-12-14-16
1 series CHROME aps Art. 9416 mm 6x0,75 - 7x0,75 - 8x0,75 - 8x1 - 9x0,75 - 9x1 - 10x1
10x0,75 - 10x1,25 - 11x0,75 - 11x1 - 11x1,25 - 12x0,75 - 12x1 - 12x1,25 - 12x1.5 - 14x1 - 14x1,25
- 14x1,5 - 16x1 - 16x1.5 - 18x1,5
1 pc. each size CHROME dies Art. 9430-type 2-3-4-5-6-7-8-9-10A 11-12-14-16
1 pc. each size CHROME dies Art. 9432 mm 6x0,75 - 7x0,75 - 8x0,75 - 8x1 - 9x0,75 - 9x1 - 10x1
10x0,75 - 10x1,25 - 11x0,75 - 11x1 - 11x1,25 - 12x0,75 - 12x1 - 12x1,25 - 12x1.5 - 14x1 - 14x1,25
- 14x1,5 - 16x1 - 16x1.5 - 18x1,5
1 pc. each size extensible tap wrenches Gr. 1 and 3
1 pc. tap wrenches T - Gr. 1
1 pc. each size die holder Ø 25.4 and 38.1 mm.
9456
Each 484,00
On request can be supplied the nutscrews in boxes with taps and dies Whitworth threads, UNC, UNF.
vuoto
CHROMESTEELTAPSANDDIES
UNIVERSAL ADJUSTABLE THREAD RESTORERS
9457GA
9457GB
9457GC
60
Prod. SCU
Universal type for EXTERNAL threads, automatically adjustable to any thread pitch.
Also for left-hand threads.
Die cast body, knurled screw and 2 steel blades, interchangeable (hardness 58 HRC).
For all 60° angle threads (Metric -UNC – UNF - NPT)
Capacity
mm 4 to 18
Capacity
inch 5/32 to 11/16
Weight
grams
225
9457GA
Each
82,40
vuoto
Two spare blades for Art. 9457 GA.
O9457GA
Per pair
26,20
vuoto
Product description as Art. 9457GA
For all 60° angle threads (Metric -UNC – UNF - NPT)
Capacity
mm 17 to 38
Capacity
inch 11/16 to 1.1/2
Weight
grams
545
9457GB
Each 120,00
vuoto
Two spare blades for Art. 9457 GB.
O9457GB
Per pair
38,60
vuoto
Universal type for OUTSIDE threads, suitable for any pitch.
To be used also on left-hand threads.
Sturdy steel body, knurled screw and 2 steel blades, interchangeable (hardness 58 HRC).
Additional handle for easier rotation.
Suitable for all threads with angle at 60° (Metric - UNC - UNF - NPT).
Capacity
mm 35 to 152
Capacity
inch 1.3/8 to 6
Weight
grams
1950
9457GC
Each 308,00
vuoto
Couple of spare blades for Art. 9457 GC.
O9457GC
Per pair
47,20
vuoto
UNIVERSALADJUSTABLETHREADRESTORERS
9457GE
9457GF
55
Product description as Art. 9457GA
For all 55° angle threads (BSW – BSF – BSP)
Capacity
inch 5/32 to 11/16
Weight
grams
225
9457GE
Each
82,40
vuoto
Two spare blades for Art. 9457 GE.
O9457GE
Per pair
26,20
vuoto
Product description as Art. 9457GA
For all 55° angle threads (BSW – BSF – BSP)
Capacity
inch 11/16 to 1.1/2
Weight
grams
545
9457GF
Each 120,00
vuoto
Two spare blades for Art. 9457 GF.
O9457GF
Per pair
35,60
vuoto
UNIVERSALADJUSTABLETHREADRESTORERS
