1274 / 1410
1274
Prices in EURO - VAT not included
1274
INOX THREADED RIVETS
13
9502GAT
1/4 ,,
APPLICATION TOOLS WITH HEXAGONAL JOINT 1/4 DIN 3126 E6,3
Machine application, to install threaded inserts Art. 9500 G and all inside threaded bushings from
M 3 to M 12. Turning depth adjustable by hex bushing.
For metric inserts
M
3
4
5
6
8
10
12
Bush hexagonal wrench opening mm 6
7
8
10
12
14
16
Overall length
mm 46
56
62
76
85
96
107
Supplier code ...............................
08070 08071 08072 08073 08074 08075 08076
9502GAT
Each 11,40 11,40 11,40 11,40 14,10 15,40 17,10
vuoto
INOXTHREADEDRIVETS
9502GB
CUTTING TOOLS
For removal of the drive shank of the inserts Art. 9500 G to 9500 GL (except for inserts with Ø
14mm.)
Size
2
4
5
6
8
9
For metric inserts Ø
M 2x0,4 and 2,2x0,45
3x0,5
3,5x0,6
4x0,7
5x0,8
6x1
For inserts with thread
UNC Nr. 2
UNC/UNF Nr. 4
UNC/UNF Nr. 6 UNC/UNF Nr. 8, UNC
Nr. 10, BSF 3/16
UNF 10, UNC 12,
BSW 3/16
UNC/UNF/BSW/
BSF 1/4
Supplier code.....................
07002
07004
07005
07006
07008
07009
9502GB
Each
3,42
3,42
3,42
3,42
3,42
3,42
Size
11
12
13
14
15
For metric inserts Ø
M 7x1, 8x1, 8x1,25 9x1 and 9x1,25
10x1, 10x1,25,
10x1,5
11x1,25 and 11x1,5
12x1, 12x1,25,
12x1,5, 12x1,75
For inserts with thread
UNC/UNF 5/16 UNC/BSW/BSF 3/8 UNF 3/8, BSP(G) 1/
8
UNC/UNF/BSW/BSF
7/16
UNC/UNF/BSW/
BSF 1/2
Supplier code.....................
07011
07012
07013
07014
07015
9502GB
Each
3,84
3,84
3,84
4,64
4,64
For inserts Ø from 14mm to 22mm tang removal may be carried out by means of a thin nose pliers (vsee from Art. 247 G to Art. 251 GB).
INOXTHREADEDRIVETS
9502GC
PULLING TOOLS
For extracting mounted threaded inserts.
Size
2
3
For metric inserts
M
3 to 10
11 to 24
For inserts with thread
UNC/UNF 4 to UNC/UNF 3/8, BSW 1/8 to
BSW 3/8, BSF 3/16 to BSF 3/8
UNC/UNF 7/16 to UNC/UNF 1/2,
BSW/BSF 7/16 to BSW/BSF 1/2
Supplier code ....................
07052
07053
9502GC
Each
17,10
20,80
INOXTHREADEDRIVETS
9503G
MF
M
Suitable for thread regeneration. Free sliding. In rhombodail-section stainless steel, spring-
shaped, it creates two perfectly concentric threads, one external coupling with the threaded hole
previously made, and one internal for screw coupling, etc. Drive shank for insertion in the hole, to
be removed after installation by using a suitable cutting tool.
SETS OF MONO-SIZE THREADED INSERTS LENGHT 1,5 x Ø
Each set contains:
1 size of threaded inserts according to the indicated quantity, 1 HSS spotting drill (except for Ø
14mm and Ø 24mm), 1 threading tap, 1 tool for the application, 1 tool for cutting (except for Ø
14mm and Ø 24mm).
In box.
Ø for male pitch
mm
3x0,5
4x0,7
5x0,8
6x1
7x1
8x1
8x1,25 9x1,25
10x1 10x1,25 10x1,5
Ø punta
mm 3,2
4,2
5,2
6,3
7,3
8,3
8,3
9,3
10,3
10,3
10,4
Insert quantity
Nr
20
20
20
20
20
20
20
15
15
15
15
Applying tool
Gr
4
6
8
9
10
11
11
12
13
13
13
Cutting tool
Gr
4
6
8
9
11
11
11
12
13
13
13
Supplier code.....................
04005 0
4007 04009 04010
04011 04013 04012 04014 04018 04017 04016
9503G
Each 29,40
29,40
30,50
32,90
41,90
41,90
41,90
46,50
44,80
44,80
44,80
Ø for male pitch
mm
12x1 12x1,25 12x1,5 12x1,75 14x1,25 14x1,5
14x2
16x1,5
16x2
18x2.5
20x2
Ø punta
mm 12,3
12,3
12,4
12,4
-
-
-
-
-
-
-
Insert quantity
Nr
10
10
10
10
10
10
10
10
10
5
5
Applying tool
Gr
15
15
15
15
17
16
16
18
18
20
21
Cutting tool
Gr
15
15
15
15
-
-
-
-
-
-
-
Supplier code.....................
04024 04023 04022 04021 04030 04029 04028 04033 04032 04034 04038
9503G
Each 50,20
50,20
50,20
50,20
56,10
56,10
56,10
68,10
68,10
80,60
87,30
Ø for male pitch
mm
20x2.5 22x2.5 24x1.5
24x2
24x3
Ø punta
mm -
-
-
-
-
Insert quantity
Nr
5
5
5
5
5
Applying tool
Gr
21
22
23
23
23
Cutting tool
Gr
-
-
-
-
-
Supplier code.....................
04037 04040 04045 04044 04043
9503G
Each 87,30 101,00 116,00 116,00 116,00
For the diameter of not supplied drill tips see Art. 9500 G.
