DIE STOCKS WITH SQUARE SHANK 1/4
13
DIE STOCKS WITH SQUARE SHANK 1/4
9497GL
Orig. Gedore - Art. 8553
Type with 1/4 female square drive to be used with ratchet heads, sliding bars, extensions, etc.
Fully made of steel. With adjusting and fixing screws.
Chrome-plated finish.
For dies Ø 20mm.
9497GL
Each 36,80
Assortment threading containing the Art. 9497 GA and GL 9497 see Art. 9387 G.
vuoto
DIESTOCKSWITHSQUARESHANK1/4
INOX THREADED RIVETS
9500G
INOX
M MF
Orig. V-Coil
DIN 8140
Suitable for thread regeneration. Free sliding. In rhombodail-section stainless steel, spring-
shaped, it creates two perfectly concentric threads, one external coupling with the threaded hole
previously made, and one internal for screw coupling, etc. Drive shank for insertion in the hole, to
be removed after installation by using a suitable cutting tool.
THREADED INSERTS ONLY
Packing units: 100pcs, not sold separately, up to Ø 12mm. From Ø 14mm up to 16mm packing
units: 50pcs, Ø 18mm and 20mm packing units: 25pcs, Ø 22 and 24mm packing units: 10pcs.
Type
M
3 0.5 4 0.7 5 0.8 5 0.8A 5 0.8B 6 1 6 1A 6 1B 7 1
8 1 8 1.25 8 1.25A 8 1.25B 9 1.25
Ø
mm 3
4
5
5
5
6
6
6
7
8
8
8
8
9
Pitch
mm 0,5
0,7
0,8
0,8
0,8
1
1
1
1
1
1,25 1,25 1,25 1,25
Thread length
mm 4,5
6
7,5
5
10
9
6
12
10,5
12
12
8
16
13,5
Supplier code.....................
07305 07307 07308 07208 07408 07309 07209 07409 07310 07312 07311 07211 07411 07313
9500G
Each 0,22 0,22 0,20 0,24 0,26 0,20 0,24 0,30 0,34 0,30 0,26 0,26 0,36 0,48
Type
M
10 1 10 1.25 10 1.25A 10 1.5 10 1.5A 10 1.5B 12 1 12 1.25 12 1.25A 12 1.5 12 1.75 12 1.75A 12 1.75B 14 1.25
Ø
mm 10
10
10
10
10
10
12
12
12
12
12
12
12
14
Pitch
mm 1
1,25 1,25 1,5
1,5
1,5
1
1,25 1,25 1,5 1,75 1,75 1,75 1,25
Thread length
mm 15
10
15
15
10
20
18
12
18
18
18
12
24
21
Supplier code.....................
07317 07216 07316 07315 07215 07415 07324 07223 07323 07322 07321 07221 07421 07327
9500G
Each 0,36 0,34 0,36 0,36 0,34 0,42 0,56 0,48 0,56 0,56 0,56 0,48 0,64 0,78
Type
M
14 1.25A 14 1.25B 14 1.25C 14 1.5 14 2 16 1.5 16 2 18 2.5 20 2 20 2.5 22 2.5 24 1.5 24 2 24 3
Ø
mm 14
14
14
14
14
16
16
18
20
20
22
24
24
24
Pitch
mm 1,25 1,25 1,25 1,5
2
1,5
2
2.5
2
2.5
2.5
1,5
2
3
Thread length
mm 8,4 12,4 16,4
21
21
24
24
27
30
30
33
36
36
36
Supplier code.....................
07128 07228 07328 07326 07325 07335 07334 07336 07340 07339 07342 07347 07346 07345
9500G
Each 0,78 0,78 0,78 0,78 0,78 0,98 0,98 1,58 2,00 2,00 2,14 2,28 2,28 2,28
