1261 / 1410
1261
Prices in EURO - VAT not included
1261
HSS TAPS AND DIES
13
9406GD
M
HSS
HSS ROUND DIES. LEFT-HAND USE.
M Coarse Metric Thread. DIN 223. 6g tolerance.
For threads
mm
3
Pitch
mm 0,5
Dimensions
mm 20x5
9406GD
Each 18,50
For similar screw dies see Art. 9353 G.
Product running out of stock
vuoto
HSSTAPSANDDIES
9406GF
MF
HSS
HSS ROUND DIES. RIGHT-HAND USE.
MF Fine Metric Thread. DIN 223. 6g tolerance.
For threads
mm
4
5
6
8
8
10
10
12
Pitch
mm
0,5
0,5 0,75 0,75
1
1
1,25
1
Dimensions
mm 20x5 20x5 20x7 25x9 25x9 30x11 30x11 38x10
9406GF
Each 9,56 9,56 9,56 9,84 9,84 11,40 11,40 16,20
For threads
mm
12
12
14
14
14
16
16
18
Pitch
mm
1,25 1,5
1
1,25 1,5
1
1,5
1,5
Dimensions
mm 38x10 38x10 38x10 38x10 38x10 45x14 45x14 45x14
9406GF
Each 16,20 16,20 17,40 17,40 17,40 24,40 24,40 24,80
For threads
mm
20
22
24
24
27
30
Pitch
mm
1,5
1,5
1,5
2
2
2
Dimensions
mm 45x14 55x16 55x16 55x16 65x18 65x18
9406GF
Each 25,80 35,80 40,30 40,30 50,50 53,70
vuoto
HSSTAPSANDDIES
9406GL
BSW
HSS
Product description as Art. 9406GF
Whitworth Thread. DIN 223. 6g tolerance.
For threads
inch
5/8
Threads per inch
Nr
11
Dimensions
mm 45x18
9406GL
Each 31,20
For similar screw dies see Art. 9360 G.
Product running out of stock
vuoto
HSSTAPSANDDIES
9406GM
BSF
HSS
Product description as Art. 9406GF
Thread: BSF Fine Whitworth pitch. DIN 223.
Tolerance 6g.
For threads
inch
5/8
3/4
1
Threads per inch
Nr
14
12
10
Dimensions
mm 45x14 45x14 55x20
9406GM
Each 96,20 101,00 143,00
For similar screw dies see Art. 9362 G.
Product running out of stock
vuoto
HSSTAPSANDDIES
9406GV
NPT
HSS
Product description as Art. 9406GF
NPT American Conic Thread, taper 1:16. DIN 223. 6g tolerance.
Per filett.
inch
1/8
3/8
1/2
Filetti per pollice
Nr
27
18
14
Dimensions
mm 30x11 45x18 45x18
9406GV
Each 73,90 97,50 157,00
For similar chains see Art. 9370 G
Product running out of stock
vuoto
HSSTAPSANDDIES
9406GZ
BSPT
HSS
Product description as Art. 9406GF
BSPT Conical GAS Thread, taper 1:16. DIN 5159. 6g tolerance.
Per filett.
inch
1.1/4
Filetti per pollice
Nr
11
Dimensions
mm 75x26
9406GZ
Each 293,00
For similar chains see Art. 9372 G
Product running out of stock
vuoto
HSSTAPSANDDIES
