1230
MACHINE TAPS
1230
13
Prices in EURO - VAT not included
9276G
LEFT USAGE
MF
HSS-E
Orig. Völkel - Art. 348
REDUCED SHANK.
LEFT-HAND USE.
ISO FINE METRIC THREAD – According to DIN 13 (DIN 374) – MF Fine Metric – Tolerance
ISO2/6H.
HSS-E. Correct chamfer. Universal type. Through holes.
Ø
mm
3
4
5
6
8
8 10 10 12 12
Pitch
mm
0,35 0,5 0,5 0,75 0,75 1
1 1,25 1 1,25
Overall length
mm 56 63 70 80 80 90 90 100 100 100
Thread length
mm 9 10 12 14 19 22 20 24 22 22
Shank Ø
mm 2,2 2,8 3,5 4,5 6
6
7
7
9
9
Shank square
mm -
2,1 2,7 3,4 4,9 4,9 5,5 5,5 7
7
9276G
Each 34,60 34,60 34,60 34,60 34,60 34,60 38,50 38,50 53,70 53,70
Ø
mm
12 14 14 14 16 16 18 18 20 20
Pitch
mm
1,5 1 1,25 1,5 1 1,5 1 1,5 1 1,5
Overall length
mm 100 100 100 100 100 100 110 110 125 125
Thread length
mm 22 22 22 22 22 22 25 25 25 25
Shank Ø
mm 9 11 11 11 12 12 14 14 16 16
Shank square
mm 7
9
9
9
9
9 11 11 12 12
9276G
Each 53,70 65,40 65,40 65,40 75,80 75,80 90,80 90,80 99,50 99,50
Ø
mm
22 22 24 24 26 27 28 30 32 32
Pitch
mm
1 1,5 1,5 2 1,5 1,5 1,5 1,5 1,5 2
Overall length
mm 125 125 140 140 140 140 140 150 150 150
Thread length
mm 25 25 28 28 28 28 28 28 28 28
Shank Ø
mm 18 18 18 18 18 20 20 22 22 22
Shank square
mm 14,5 14,5 14,5 14,5 14,5 16 16 18 18 18
9276G
Each 125,00 125,00 146,00 146,00 146,00 183,00 183,00 209,00 259,00 259,00
vuoto
MACHINETAPS
9277G
MF
HSS-E
Orig. Völkel - Art. 394
REDUCED SHANK.
RIGHT-HAND USE.
ISO FINE METRIC THREAD – According to DIN 13 (DIN 374) – MF Fine Metric – Tolerance
ISO2/6H.
HSS-E. Short chamfer. Universal type. Through and blind holes.
Ø
mm
4
5
6
8
8 10 10 12 12 12 14 14 14 16 16 18 18 18
Pitch
mm
0,35 0,5 0,75 0,75 1
1 1,25 1 1,25 1,5 1 1,25 1,5 1 1,5 1 1,5 2
Overall length
mm 63 70 80 80 90 90 100 100 100 100 100 100 100 100 100 110 110 125
Thread length
mm 10 12 14 19 22 20 24 22 22 22 22 22 22 22 22 25 25 34
Shank Ø
mm 2,8 3,5 4,5 6
6
7
7
9
9
9 11 11 11 12 12 14 14 14
Shank square
mm 2,1 2,7 3,4 4,9 4,9 5,5 5,5 7
7
7
9
9
9
9
9 11 11 11
9277G
Each 14,40 14,40 14,40 14,40 14,40 17,30 17,30 22,50 23,10 22,50 27,90 27,90 27,90 33,10 33,10 39,10 39,10 39,10
Ø
mm
20 20 20 22 22 24 24 24 26 27 27 28 30 30 32 36 36
Pitch
mm
1 1,5 2
1 1,5 1 1,5 2 1,5 1,5 2 1,5 1,5 2 1,5 1,5 2
Overall length
mm 125 125 140 125 125 140 140 140 140 140 140 140 150 150 150 170 170
Thread length
mm 25 25 34 25 25 28 28 28 28 28 28 28 28 28 28 30 30
Shank Ø
mm 16 16 16 18 18 18 18 18 18 20 20 20 22 22 22 28 28
Shank square
mm 12 12 12 14,5 14,5 14,5 14,5 14,5 14,5 16 16 16 18 18 18 22 22
9277G
Each 42,60 42,60 42,60 53,70 53,70 62,90 62,90 62,90 62,90 78,40 78,40 78,40 90,10 90,10 116,00 145,00 145,00
MACHINETAPS
9284G
MF
HSS-E
Orig. Völkel - Art. 397
Product description as Art. 9277G
HSS-E. Short chamfer. Type with approx. 35° spiral flute for holes with dia. more than 1 1/2. For
metals up to R 900 N/mm². Deep blind holes.
Ø
mm
3
4
4
5
6
8
8
10
Pitch
mm
0,35 0,35 0,5
0,5
0,5 0,75
1
1
Overall length
mm 56
63
63
70
80
80
90
90
Thread length
mm 5
5
5
5
5
8
10
10
Shank Ø
mm 2,2
2,8
2,8
3,5
4,5
6
6
7
Shank square
mm -
2,1
2,1
2,7
3,4
4,9
4,9
5,5
9284G
Each 18,20 18,20 18,20 18,20 18,20 18,20 18,20 21,50
Ø
mm
10
12
12
12
14
14
14
16
Pitch
mm
1,25
1
1,25 1,5
1
1,25 1,5
1
Overall length
mm 100 100 100 100 100 100 100 100
Thread length
mm 16
11
15
15
11
15
15
12
Shank Ø
mm 7
9
9
9
11
11
11
12
Shank square
mm 5,5
7
7
7
9
9
9
9
9284G
Each 21,50 27,80 27,80 27,80 33,90 33,90 33,90 39,20
Ø
mm
16
18
20
22
24
24
27
30
Pitch
mm
1,5
1,5
1,5
1,5
1,5
2
2
2
Overall length
mm 100 110 125 125 140 140 140 150
Thread length
mm 15
17
17
17
20
20
20
22
Shank Ø
mm 12
14
16
18
18
18
20
22
Shank square
mm 9
11
12 14,5 14,5 14,5 16
18
9284G
Each 39,20 49,10 54,50 66,50 79,90 79,90 95,80 109,00
MACHINETAPS
