1229
MACHINE TAP WITH COLOURED RINGS
1229
13
Prices in EURO - VAT not included
9273GP
new
M
HSS-E
Orig. Völkel - Art. 365
YELLOW collar.
Made of High-Speed steel class HSS-E, particularly treated for greater performance.
Ground and polished after hardening.
Reinforced shank (12 mm, passing through shank), with a helix at 40 ° for deep blind holes.
Thread: Metric - Coarse M - DIN 13 (DIN 371/376).
Use Right.
For ALUMINIUM, its alloys and long chipping materials.
Ø
mm
3
4
5
6
8
10 12 14 16
Pitch
mm 0,5 0,7 0,8
1 1,25 1,5 1,75 2
2
Overall length
mm 56 63 70 80 90 100 110 110 110
Thread length
mm 6
7
8
10 14 16 18 20 22
Shank Ø
mm 3,5 4,5
6
6
8
10
9
11 12
Shank square
mm 2,7 3,4 4,9 4,9 6,2
8
7
9
9
9273GP
Each 15,90 15,90 17,20 17,20 19,60 23,80 28,80 37,80 42,90
vuoto
MACHINETAPWITHCOLOUREDRINGS
9273GT
new
M
HSS-E
Orig. Völkel - Art. 357
ORANGE collar.
Made of High-Speed steel class HSS-E, particularly treated for greater performance.
Ground and polished after hardening.
Reinforced shank (12 mm, passing through shank), with short chamfer for passing through and
blind holes.
Thread: Metric - Coarse M - DIN 13 (DIN 371/376).
Use Right.
For BRASS and short chipping materials.
Ø
mm
3
4
5
6
8
10 12 14 16
Pitch
mm 0,5 0,7 0,8
1 1,25 1,5 1,75 2
2
Overall length
mm 56 63 70 80 90 100 110 110 110
Thread length
mm 11 13 16 19 22 24 29 30 32
Shank Ø
mm 3,5 4,5
6
6
8
10
9
11 12
Shank square
mm 2,7 3,4 4,9 4,9 6,2
8
7
9
9
9273GT
Each 13,70 13,70 14,70 14,70 16,90 20,40 24,70 31,50 36,20
vuoto
MACHINETAPWITHCOLOUREDRINGS
MACHINE TAPS
9275G
MF
HSS-E
Orig. Völkel - Art. 395
REDUCED SHANK.
RIGHT-HAND USE.
ISO FINE METRIC THREAD – According to DIN 13 (DIN 374) – MF Fine Metric – Tolerance
ISO2/6H.
HSS-E. Correct chamfer. Universal type. Through holes.
Ø
mm
3
4
4
5
6
6
7
8
8
10 10 10 11 12 12 12
Pitch
mm
0,35 0,35 0,5 0,5 0,5 0,75 0,75 0,75 1 0,75 1 1,25 1
1 1,25 1,5
Overall length
mm 56 63 63 70 80 80 80 80 90 90 90 100 90 100 100 100
Thread length
mm 9
10 10 12 14 14 14 19 22 20 20 24 20 22 22 22
Shank Ø
mm 2,2 2,8 2,8 3,5 4,5 4,5 5,5
6
6
7
7
7
8
9
9
9
Shank square
mm -
2,1 2,1 2,7 3,4 3,4 4,3 4,9 4,9 5,5 5,5 5,5 6,2
7
7
7
9275G
Each 16,10 16,10 16,10 16,10 16,10 16,10 16,10 16,10 16,10 18,60 18,60 18,60 25,60 25,60 25,60 25,60
Ø
mm
14 14 14 15 16 16 18 18 20 20 22 22 24 24 24 25
Pitch
mm
1 1,25 1,5
1
1
1,5
1
1,5
1
1,5
1
1,5
1
1,5
2
1,5
Overall length
mm 100 100 100 100 100 100 110 110 125 125 125 125 140 140 140 140
Thread length
mm 22 22 22 22 22 22 25 25 25 25 25 25 28 28 28 28
Shank Ø
mm 11 11 11 12 12 12 14 14 16 16 18 18 18 18 18 18
Shank square
mm 9
9
9
9
9
9
11 11 12 12 14,5 14,5 14,5 14,5 14,5 14,5
9275G
Each 32,80 32,80 32,80 36,10 36,80 36,80 44,70 44,70 49,50 49,50 60,70 60,70 70,30 70,30 70,30 75,10
Ø
mm
26 27 27 28 30 30 30 32 33 34 36 36 36
Pitch
mm
1,5 1,5
2
1,5
1
1,5
2
1,5 1,5 1,5 1,5
2
3
Overall length
mm 140 140 140 140 150 150 150 150 160 170 170 170 200
Thread length
mm 28 28 28 28 28 28 28 28 30 30 30 30 56
Shank Ø
mm 18 20 20 20 22 22 22 22 25 28 28 28 28
Shank square
mm 14,5 16 16 16 18 18 18 18 20 22 22 22 22
9275G
Each 75,10 89,40 89,40 89,40 101,00 101,00 101,00 123,00 123,00 123,00 154,00 154,00 154,00
