1227
MACHINE TAP WITH COLOURED RINGS
1227
13
Prices in EURO - VAT not included
9272GL
INOX
M
HSS-E
VAP
Orig. Völkel - Art. 352
WHITE collar.
Stainless SUPER-FAST class HSS-E, especially treated for superior performance.
Vaporized. Ground and polished after hardening.
Reinforced shank (12mm, reduced shank), with chamfer suitable for through holes.
Thread: Coarse Metric M - DIN 13 (DIN 371/376).
Right-hand use.
For all kinds of stainless steel and long chip steel with R up to 1000 N/mm².
Ø
mm
3
4
5
6
8
10
12
Pitch
mm 0,5
0,7
0,8
1
1,25
1,5
1,75
Overall length
mm 56
63
70
80
90
100
110
Thread length
mm 11
13
16
19
22
24
29
Shank Ø
mm 3,5
4,5
6
6
8
10
9
Shank square
mm 2,7
3,4
4,9
4,9
6,2
8
7
9272GL
Each 13,30 13,30 14,30 14,30 16,40 20,10 24,10
Ø
mm
14
16
18
20
Pitch
mm 2
2
2,5
2,5
Overall length
mm 110
110
125
140
Thread length
mm 30
32
34
34
Shank Ø
mm 11
12
14
16
Shank square
mm 9
9
11
12
9272GL
Each 31,40 36,20 51,10 70,40
Taps with similar characteristics for UNC, UNF and G (BSP) threads can be supplied on request.
vuoto
MACHINETAPWITHCOLOUREDRINGS
9272GP
INOX
M
HSS-E
VAP
Orig. Völkel - Art. 362
Product description as Art. 9272GL
Reinforced shank (12mm, reduced shank), with 39° spiral flute for deep blind holes.
Thread: Coarse Metric M - DIN 13 (DIN 371/376).
Right-hand use.
For all kinds of stainless steel and long chip steel with R up to 1000 N/mm².
Ø
mm
3
4
5
6
8
10
12
Pitch
mm 0,5
0,7
0,8
1
1,25
1,5
1,75
Overall length
mm 56
63
70
80
90
100
110
Thread length
mm 6
7
8
10
14
16
18
Shank Ø
mm 3,5
4,5
6
6
8
10
9
Shank square
mm 2,7
3,4
4,9
4,9
6,2
8
7
9272GP
Each 16,60 16,60 17,90 17,90 20,70 24,70 30,40
Ø
mm
14
16
18
20
Pitch
mm 2
2
2,5
2,5
Overall length
mm 110
110
125
140
Thread length
mm 20
22
25
25
Shank Ø
mm 11
12
14
16
Shank square
mm 9
9
11
12
9272GP
Each 39,20 44,70 62,30 87,30
Taps with similar characteristics for UNC, UNF and G (BSP) threads can be supplied on request.
vuoto
MACHINETAPWITHCOLOUREDRINGS
9272GR
INOX
M
HSS-E
Orig. Völkel - Art. 354
BLUE collar.
Stainless SUPER-FAST class HSS-E, especially treated for superior performance.
Ground and polished after hardening.
Reinforced shank (12mm, reduced shank), correct chamfer for through holes.
Thread: Coarse Metric M - DIN 13 (DIN 371/376).
Right-hand use.
For all kinds of stainless steel and long chip steel with R up to 1000 N/mm².
Ø
mm
3
4
5
6
8
10
12
Pitch
mm 0,5
0,7
0,8
1
1,25
1,5
1,75
Overall length
mm 56
63
70
80
90
100
110
Thread length
mm 11
13
16
19
22
24
29
Shank Ø
mm 3,5
4,5
6
6
8
10
9
Shank square
mm 2,7
3,4
4,9
4,9
6,2
8
7
9272GR
Each 12,70 12,70 13,80 13,80 16,10 17,60 23,30
Ø
mm
14
16
18
20
Pitch
mm 2
2
2,5
2,5
Overall length
mm 110
110
125
140
Thread length
mm 30
32
34
34
Shank Ø
mm 11
12
14
16
Shank square
mm 9
9
11
12
9272GR
Each 32,10 34,40 47,20 65,50
vuoto
MACHINETAPWITHCOLOUREDRINGS
