ROUND DIES
1236
13
Prices in EURO - VAT not included
9358G
LEFT USAGE
MF
HSS
Orig. Völkel - Art. 262
Product description as Art. 9350G
ISO FINE METRIC THREAD, according to DIN 13 - MF Fine Metric – Tolerance 6g
LEFT-HAND USE.
HSS. Normal chamfer. For steel with R up to 800 N/mm^2.
Ø
mm
6
8
8
10
10
12
12
Pitch
mm
0,75
0,75
1
1
1,25
1
1,25
Dimensions
mm 20x7 25x9 25x9 30x11 30x11 38x10 38x10
9358G
Each 18,50 20,10 20,10 24,10 24,10 29,40 29,40
Ø
mm
12
14
14
16
16
18
20
Pitch
mm
1,5
1,25
1,5
1
1,5
1,5
1,5
Dimensions
mm 38x10 38x10 38x10 45x14 45x14 45x14 45x14
9358G
Each 29,40 30,50 30,50 41,60 41,60 46,50 46,50
Ø
mm
22
24
24
30
Pitch
mm
1,5
1,5
2
2
Dimensions
mm 55x16 55x16 55x16 65x18
9358G
Each 66,10 66,10 66,10 129,00
