952 / 1410
952
Prices in EURO - VAT not included
952
INDICATOR STANDS
11
4421BE
Orig. MIB - Art. 06071005
Magnetic model. Implementation strengthened.
Magnetic-mount adhesion and detachment.
Dimensions: length. 60 mm, min. 50 mm, alt. 55 mm.
The horizontal arm can be rotated and tilted, with micrometric adjustment.
Total height: 281 mm. Column diameter mm 16.
Horizontal arm length 200 mm, diameter 12 mm.
For comparators with 8 mm diameter.
Without comparator.
Magnet force
N 600
4421BE
Each 42,30
vuoto
INDICATORSTANDS
4421C
Orig. MIB - Art. 06071025
Magnetic type. Heavy-duty machining, prismatic base.
Very strong magnetic adhesion with lever insertion and detachment.
Base dimensions: length 63mm, width 50mm, height 55mm.
The horizontal arm swivels and tilts, with micrometer adjustment.
Total height 290mm. Column diameter 16mm.
Horizontal arm length 250mm, diameter 16mm.
For comparators with coupling Ø 8mm.
Without dial indicator.
Magnet force
N 800
4421C
Each 90,80
vuoto
INDICATORSTANDS
4421ET
Prod. SCU
Magnetic model. Precision fine finish, with central tensioning system, prism-shaped base.
High magnetic force with switch on/off.
Chromed arms and micrometric adjustment.
Base dimensions: length 40mm, width 30mm, height 35mm.
Total height 210mm.
Active radius 150mm.
Holder opening for dial indicators Ø 8mm.
Without dial indicator.
Magnet force
N 200
4421ET
Each 76,10
vuoto
INDICATORSTANDS
4421F
Orig. MIB - Art. 06071002
Magnetic model. Precision fine finish, with central tensioning system, prism-shaped base.
Big magnetic force with switch on/off.
Chromed arms and micrometric adjustment.
Base dimensions: length 65mm, width 50mm, height 55mm.
Total height 380mm.
Range of action 310mm.
Holder opening for dial indicators Ø 8mm.
Without dial indicator.
Magnet force
N 600
4421F
Each 64,20
vuoto
INDICATORSTANDS
4421GA
Prod. SCU
Professional/industrial model with magnetic base. High precision, fine finish, very stable and
sturdy, with central tensioning system. Chromed arms with precision articulations, guided travel
and micrometric adjustment.
Round base dimensions 40mm x height 30mm. Active radius 200mm. Total height 335mm.
Holder opening for dial indicators Ø 8mm and indicator/pointers with dovetail clamp.
Without dial indicator.
Magnet force
N 300
4421GA
Each 379,00
vuoto
INDICATORSTANDS
