949 / 1410
949
Prices in EURO - VAT not included
949
DIAL TEST INDICATORS, SWIVEL CONTACT POINT
11
4412GM
2/1000
Very high precision model, with dial Ø 40mm, 2/1000 graduations.
Stem Ø 8mm x h 6, inserted from above, travel 0.2mm, for tolerance ±0,1 mm forward-backward
with front movement.
Swivel range of stylus in hard metal 240°.
To be mounted on articulated holder Art. 4412 GS and arch centering Art. 4412 GT by joint Art.
O4412 GM 4 or 8.
Rod with contact point, length 12mm.
4412GM
Each 211,00
For drive Ø 4 mm see. Art. O4412 GM 4.
vuoto
Stem fittings Ø 4 mm, inserted in the head, on comparators Art. 4412 GF - L - M. (Not supplied).
O4412GM 4
Each 18,30
vuoto
Stem fittings Ø 8 mm, inserted in the head, on comparators Art. 4412 GF - L - M. (Supplied).
O4412GM 8
Each 18,30
vuoto
DIALTEST INDICATORS,SWIVELCONTACTPOINT
4412GS
Articulated support for comparators with hole for attacks Ø mm 4 e 8 for dial gauges with dovetail.
Dimensions 80x12x6mm.
4412GS
Each 28,70
vuoto
DIALTEST INDICATORS,SWIVELCONTACTPOINT
4412GT
Centering arches with connection pin Ø 8 mm and holes for attacks comparators Ø 4 and 8 mm.
4412GT
Each 62,50
vuoto
DIALTEST INDICATORS,SWIVELCONTACTPOINT
PRECISION DIAL INDICATORS WITH MAGNETIC HOLDER
4414G
1/100
Prod. SCU - Orig. Käfer
With prism-shapedbase and lateral magnetic holders. Can be used over flat or round surfaces
and in many other applications.
Handy and easy to use.
Indicator holding articulation can swing horizontally at 360°.
Vertically 30°.
Dimensions: support base: 72x37x26mm. Magnetic force KN 260.
Arm gauge 35mm.
Dial indicator 4404 GB with magnetic holder.
4414G
Each 238,10
vuoto
PRECISIONDIAL INDICATORSWITHMAGNETICHOLDER
4414GS
Product description as Art. 4414G
Only magnetic holder without dial indicator.
4414GS
Each 168,00
For similar model, but with flat base see Art. 4421 A.
vuoto
PRECISIONDIAL INDICATORSWITHMAGNETICHOLDER
HIGH PRECISION DIAL INDICATORS
4415G
1/1000
Orig. MIB - Art. 01024001
DIN 878. Division 1/1000. With 2 hands to indicate tenths, hundredths and thousandths of a
millimetre.
Reset by turning the dial. Metal box.
Dial Ø
mm 58
Drive Ø
mm 8 h 6
Measuring capacity
mm 1
Each pointer revolution
mm 0,1
4415G
Each 104,00
vuoto
HIGHPRECISIONDIAL INDICATORS
