RACK AND PINION JACKS
8
RACK AND PINION JACKS
2228G 1
Orig. Peddinghaus - Art. 8000-8100-8200-8300
Manufactured according to DIN 7355 standards. Completely made of steel. Bolted body can be
easily disassembled and inspected. Steel gears, with hardened interchangeable operating parts.
Maximum safety and duration. Safety winch to brake descent. Side support and upper support
with the same load capacity.
Type with safety winch.
Max load capacity
Kg
1500
3000
5000
10000
Ratio
simple
simple
double
double
Stroke
mm 360
425
425
490
Max height as closed
mm 600
730
730
800
Weight
Kg
14
20
28
46
2228G 1
Each 315,00
351,00
389,00
479,00
vuoto
RACKANDPINION JACKS
2228GA
Prod. SCU
With a smaller height compared to those manufactured in compliance with DIN 7355 standards.
Completely made of steel. Bolted body can be easily disassembled and inspected. Steel gears
with hardened interchangeable operating parts, Maximum safety and duration. Safety winch to
brake descent. Lateral support and upper support with the same load capacity.
PARTICULARLY INDICATED FOR LIFTING HEAVY MOTOR VEHICLES,
AGRICULTURAL MACHINES, ETC.
With safety winch.
Max load capacity
Kg
1500
3000
5000
10000
Ratio
simple
simple
double
double
Stroke
mm 300
300
300
300
Max height as closed
mm 570
570
600
650
Weight
Kg
11
18
22
38
2228GA
Each 532,00
605,00
714,00 1.120,00
vuoto
RACKANDPINION JACKS
2228GBN
Manufactured in compliance with DIN 7355 standards. Completely made of steel. Bolted body
can be easily disassembled and inspected. Steel gears with hardened interchangeable operating
parts, Maximum safety and duration. Safety winch to brake descent. Lateral support and upper
support with the same load capacity.
With safety winch.
Max load capacity
Kg
1500
3000
5000
10000
Ratio
simple
simple
double
double
Stroke
mm 350
350
300
300
Max height as closed
mm 725
725
725
800
Weight
Kg
12
20
24
42
2228GBN
Each 532,00
605,00
714,00 1.120,00
vuoto
RACKANDPINION JACKS
2228GCN
Product description as Art. 2228GBN
With safety winch and cric.
Max load capacity
Kg
1500
3000
5000
10000
Ratio
simple
simple
double
double
Stroke
mm 350
350
300
300
Max height as closed
mm 725
725
725
800
Weight
Kg
12
20
24
42
2228GCN
Each 617,00
690,00
818,00 1.220,00
vuoto
RACKANDPINION JACKS
2230GN
Manufactured in compliance with DIN 7355 standards. Steel gears with hardened
interchangeable operating parts. With movable support. It allows to place the jack quickly by using
all the available stroke. Safety winch. Movable support and upper support with the same load
capacity.
Max load capacity
Kg
3000
5000
10000
Ratio
simple
double
double
Stroke
mm 350
300
300
Max height as closed
mm 725
725
800
Weight
Kg
23
29
46
2230GN
Each 747,00
889,00 1.330,00
vuoto
RACKANDPINION JACKS
