405 / 1410
405
Prices in EURO - VAT not included
5
405
UNIVERSAL DOUBLE-GRIP PULLERS
UNIVERSAL DOUBLE-GRIP PULLERS
1423GE
Orig. Buco - Art. 80
Standard type, with bolster and very hardened arms. Large working opening. Arms for inside/
outside use.
Size
1
1A
Max opening
mm 100
150
Useful length
mm 100
100
Weight
Kg
0,6
0,7
1423GE
Each 82,90 87,30
vuoto
UNIVERSALDOUBLE-GRIPPULLERS
SETS OF ASSORTED DOUBLE-GRIP EXTRACTORS
1423GS
Orig. Buco - Art. 10/ST1
Composed of 5 extractors Art. 1423 G with elegant and handy wooden display stand also for
workshops.
Extractors size: 1 - 1A - 2 - 2A - 3.
1423GS
Each 861,00
vuoto
SETSOFASSORTEDDOUBLE-GRIPEXTRACTORS
HYDRAULIC DOUBLE-GRIP PULLERS
1424G
Orig. Buco - Art. HY 10
Hydraulic pivot type.
Made of steel, arms are forged in one piece. H-beam arm rest with trapezoidal stiffener. Heavy-
duty type. Arms with inside/outside use: the operator needs only to extract them from support and
turn them. Easy adjustment by means of light pressure on arms at the required distance. In
traction it stops automatically.
Acting by means of a key on the upper screw of the pivot, the operator will obtain hydraulic
pressures equal to some tons.
Size
2A
3
3A
4
Max opening
mm 200
250
350
530
Useful length
mm 150
200
200
200
Maximum pressure:
t.
8
13
13
15
Weight
Kg
3,6
8,1
9
13
1424G
Each 508,00 662,00 695,00 892,00
For spare arms and extensions see Art. 1423 GA and 1423 GB.
vuoto
HYDRAULICDOUBLE-GRIPPULLERS
UNIVERSAL DOUBLE-GRIP PULLERS, THIN ARMS
1424GA
GRADUATED
Orig. Gedore
Hot-stamped steel.
Wide range of use, inside/outside use. Normal and long arms, interchangeable, sliding on ground
guides with thin ends and feet to be inserted in very narrow spaces. This kind of arms ensures
parallel traction stresses. Zinc-chrome plated finish.
Max opening
mm
100
140
160
200
Useful length
mm
100
100
150
150
Maximum pressure:
t.
2
2,5
5
5
Weight
Kg
1
1,2
3
3,2
Height a
mm
3,6
3,6
5
5
Height b
mm
7,5
7,5
7
7
Height c
mm
13
13
17
17
Height D
mm
27
27
40
40
Screw x length Ø
mm M 14x1,5x140 M 14x1,5x140
G 1/2x210
G 1/2x210
Supplier code.....................
1.06/S1
1.06/S1A
1.06/S2
1.06/S2A
1424GA
Each
141,00
150,00
234,00
257,00
Spare arms can be supplied on request. For spare screw see Art. 1455 GA.
vuoto
UNIVERSALDOUBLE-GRIPPULLERS,THINARMS
