400 / 1410
400
Prices in EURO - VAT not included
5
400
EXTRACTORS FOR BALL BEARINGS
EXTRACTORS FOR BALL BEARINGS
1417A
Orig. Gedore
Suitable for extracting ball bearings jammed into seats and impossible to reach through internal/
external gripping.
Thanks to the interchangeable arms, the bearing is clamped in the space between the balls inside
the ring gear. The extractor is composed of: screw-type clamp, flange, force lever and
interchangeable arms.
Forged and hardened steel.
PULLERS WITHOUT ARMS complete with screw-type clamp, flange and lever.
Size
1
2
3
4
5
Presser screw length
mm 160
195
210
230
235
Supplier code ....................
1.29/1 1.29/2 1.29/3 1.29/4 1.29/5
1417A
Each 29,60 43,80 57,20 71,10 84,50
Supplied without arms.
Size 2 is running out of stock
When the stocks will be run out, the size 2 is replaced with the size 1.
vuoto
EXTRACTORSFORBALLBEARINGS
1417F
Product description as Art. 1417A
Forged and hardened steel.
INTERCHANGEABLE ARMS (in series of 4 pieces).
Size
11
12
13
14
Overall length
mm
145
145
177
177
For extractors Art.
1417 to 1
1417 to 1
1417 to 2 (1)
1417 to 2 (1)
Supplier code ....................
1.29/10
1.29/15
1.29/20
1.29/25
1417F
Per series
77,10
77,60
70,50
80,70
Size
15
16
17
18
Overall length
mm
185
187
235
236
For extractors Art.
1417 to 2 (1) -3 1417 to 3
1417 to 4
1417 to 4-5
Supplier code ....................
1.29/30
1.29/35
1.29/40
1.29/45
1417F
Per series 106,00
113,00
130,00
148,00
For couplings between Art. 1417 A - 1417 F and ball bearings type 6000 see technical table no. 8 a at the end of the catalogue.
Size 13 is running out of stock
When the stocks will be run out, the size 13 is replaced with the size 12.
vuoto
EXTRACTORSFORBALLBEARINGS
1417G
Orig. Buco - Art. 44
Product description as Art. 1417A
Made of forged and hardened steel. EXTRACTORS WITHOUT ARMS, complete with setscrew,
flange, operating force lever.
Size
1
2
3
4
5
Presser screw length
mm 170
210
230
275
280
1417G
Each 45,20 59,60 61,60 65,40 84,70
Supplied without arms.
vuoto
EXTRACTORSFORBALLBEARINGS
1417GB
Orig. Buco - Art. 48
Product description as Art. 1417A
Made of forged and hardened steel. INTERCHANGEABLE ARMS (set of 4 pieces)
Size
11
12
13
14
Overall length
mm
140
145
175
175
For extractors Art.
1417 G 1
1417 G 1
1417 G 2
1417 G 2-3
1417GB
Per series
74,40
76,50
92,90
92,90
Size
15
16
17
18
Overall length
mm
185
190
235
235
For extractors Art.
1417 G 2-3-4-5 1417 G 3-5
1417 G 4
1417 G 3-5
1417GB
Per series
92,90
97,20
110,00
161,00
For couplings between Art. 1417 G - 1417 GB and ball bearings type 6000 see technical table no. 8 b at the end of the catalogue.
vuoto
