402 / 1410
402
Prices in EURO - VAT not included
5
402
SETS OF ASSORTED EXTRACTORS FOR BALL BEARINGS
1419GA
1419GB
1419GE
Orig. Gedore - Art. 1.92/1
Suitable for a safe and precise extraction of ball bearings jammed into seats and impossible to
reach through internal/external gripping. Round flange in special steel with passing-through holes
for the clamping of pulling arms. This allows to use all the strength deriving from the threaded
screw and obtain quicker and better results.
The set contains:
1 threaded screw M10, length 115mm
3 flanges with holes
1 4-arm set 10 gr, length 120mm for bearings ISO:
6000-6001-6002-6003-6200
1 4-arm set 20 gr, length 125mm for bearings ISO:
6201-6202
1 4-arm set 30 gr, length 130mm for bearings ISO:
6203-6004-6005-6006-6300
1 4-arm set 40 gr, length 135mm for bearings ISO:
6301-6302-6007-6008-6204-6009-6010-6303-6304
In sturdy case made of synthetic material.
1419GA
Each 605,00
vuoto
Orig. Gedore - Art. 1.92/2
Product description as Art. 1419GA
The set contains:
1 threaded screw M14, length 180mm, with adapter
3 flanges with holes
3 support rings (necessary for bearings ISO 6407-6310-6311)
1 4-arm set 50 gr, length 140mm for bearing ISO:
6011-6012-6206-6207
1 4-arm set 60 gr, length 145mm for bearings ISO:
6305-6403-6306-6307-6208-6209-6210-6211-6407
1 4-arm set 70 gr, length 150mm for bearings ISO:
6404-6405-6406-6308-6309-6212-6310-6311
In sturdy case made of synthetic material.
1419GB
Each 624,00
vuoto
Orig. Gedore - Art. 1.92/12
Product description as Art. 1419GA
The set contains:
Assortments Art. 1419 GA and 1419 GB.
In sturdy case made of synthetic material.
1419GE
Each 1.230,00
vuoto
SETSOFASSORTEDEXTRACTORSFORBALLBEARINGS
RAPID ADJUSTMENT PULLERS
1420G
Orig. Gedore
Rapid-adjustment by rotation of the knurled ring nut containing the opening and closing
mechanism of the 3 arms. It allows a rapid and precise positioning of the arms without any
additional adjustments. High-precision threaded screw. Special steel body and arms, thermo-
chemically hardened to support screw high pressures and high arms extraction values.Pointed or
ball-shaped tip, interchangeable and reversible for a wide range of use. Particularly suitable for
the extraction of ball bearings in any position.
Max opening
mm
150
250
Useful length
mm 130
250
Maximum pressure:
t.
6,5
6,5
Weight
Kg
2,4
3,4
Screw x length Ø
mm G 1/2x250 G 1/2x350
Supplier code ....................
1.09/1
1.09/2
1420G
Each 474,00
672,00
For spare screw see Art. 1455 GA.
vuoto
RAPIDADJUSTMENTPULLERS
EXTRACTORS FOR BATTERY TERMINALS.
1421GA
Orig. Buco - Art. 40
Used for removing windscreen wipers and battery terminals jammed because of oxidation.
The pressure exerted on the spring allows to use one hand only. Zinc-plated finish.
Size
1
2
Max opening
mm 55
70
Useful length
mm 45
65
1421GA
Each 44,70 52,60
vuoto
EXTRACTORSFORBATTERYTERMINALS.
