406 / 1410
406
Prices in EURO - VAT not included
5
406
DOUBLE-GRIP PULLERS, THIN ARMS
DOUBLE-GRIP PULLERS, THIN ARMS
1424GB
GRADUATED
Orig. Gedore - Art. 1.06/AS
Hot-stamped steel.
Wide range of use, inside/outside use. Normal and long arms supplied, interchangeable, sliding
on ground guides with thin ends and feet to be inserted in very narrow spaces. This kind of arms
ensures parallel traction stresses. Zinc-chrome plated finish.
Composition:
1 cross-beam rest for 2 arms max. aperture 140mm
2 arms length 100mm
2 arms length 200mm
2 arms length 250mm
1424GB
Per series 404,00
Spare arms can be supplied on request.
vuoto
DOUBLE-GRIPPULLERS,THINARMS
UNIVERSAL DOUBLE-GRIP PULLERS, THIN ARMS
1424GE
Orig. Buco - Art. 16
Made of forged and hardened steel.
Wide range of use, inside/outside use. Normal and long arms, interchangeable, sliding on ground
guides with thin feet to be inserted in very narrow spaces. This kind of arms gives parallel traction
stresses. Zinc-chrome plated finish.
Max opening
mm
80
130
160
200
Useful length
mm 100
100
150
150
Maximum pressure:
t.
4,5
4,5
6,5
6,5
Weight
Kg
1
1,2
3
3,2
Height a
mm 3,6
3,6
5
5
Height b
mm 60
60
80
80
Height c
mm 13
13
17
17
Height D
mm 27
27
40
40
1424GE
Each 123,00 132,00 226,00 250,00
vuoto
UNIVERSALDOUBLE-GRIPPULLERS,THINARMS
ARMS FOR PULLERS
1424GF
Orig. Buco
Couple of arms complete with connections and bolts. For Art. 1424 GE.
Standard type.
Useful length
mm
100
150
For extractors opening
mm 80-130 160-200
1424GF
Per pair
79,10 143,00
vuoto
ARMSFORPULLERS
1424GH
Product description as Art. 1424GF
Long type.
Useful length
mm
200
220
250
300
For extractors opening
mm 80-130 160-200 80-130 160-200
1424GH
Per pair 102,00 173,00 118,00 179,00
vuoto
ARMSFORPULLERS
UNIVERSAL DOUBLE-GRIP PULLERS
1424GL
GRADUATED
Orig. Gedore
Hot-stamped steel.
Wide range of use, inside/outside use. Normal and long arms, interchangeable, sliding on ground
guides. This kind of arms ensures parallel traction stresses. Zinc-chrome plated finish.
Max opening
mm
90
130
160
200
250
350
520
Useful length
mm 100
100
150
150
200
200
200
Weight
Kg
1,1
1,3
3,2
3,6
7,8
9,2
15,2
Screw x length Ø
mm M
14x1,5x140
M
14x1,5x140
G 1/
2x210
G 1/
2x210
G 3/
4x280
G 3/
4x280
G 1x310
Supplier code ....................
1.06/1 1.06/1A 1.06/2 1.06/2A 1.06/3 1.06/3A 1.06/4
1424GL
Each 104,00 112,00 189,00 207,00 343,00 376,00 553,00
For spare arms and other items see Art. 1424 GPA - RA.
For spare screw (manual or hydraulic) see Art. 1455 GA-GB.
Art. 1424 GL 520 without graduation.
vuoto
UNIVERSALDOUBLE-GRIPPULLERS
