ELECTRONIC TORQUE WRENCHES, TORCO TRONIC
3
Prices in EURO - VAT not included 209
810GR
9x12 14x18
Orig. Gedore - Torcotronic III
Latest generation digital torque wrench used for TORQUE and ANGULAR measurements.
Microprocessor controls with CE marking. 1/2” reversible ratchet disc for tightening on the left and
on the right, removable via the ratchet insert keys and can be attached with female coupling
measuring 9x12 (as per Art. 810 GR 120) o mm 14x18 (Art. 810 GR 350). Graphic display with
rear lit liquid crystal display. Simple operation with menu icons and four function keys. Dual scale in
Nm and .
High level of measuring accuracy: ± 1% ±1 digit / ± 1% ±1° at 360° with a clamping speed to 4°/s.
Is able to program various measuring distances depending on the inserts which have been
installed. Keypad lock, visual display with 3 LEDs and a buzzer.
Equipped with items specified as per DIN ISO 6789:2003. Type I, Class C. Approved in
accordance with TÜV SÜD regulations. Comes complete with a large memory, which is also able
to measure modes and select 5 different clamping settings. Direct PC connection via USB cable,
software available on disk.
Batteries available in AA format (as per Art. SCU 3600 E) or with NiMH batteries.
Provided with casing.
Size 120 350
Inserts drive mm 9x12 14x18
Tightening capacity Nm 10-120 70-350
Tightening capacity 7,4-88,5 51,6-258,2
Scale division Nm 0,1 Nm/0,1° 0,1 Nm/0,1°
Overall length mm 565 701
Weight Kg 0,9 1,2
Supplier code..................... TT 3 KH 120 TT 3 KH 350
810GR Each 1.620,00 2.000,00
In order to make full use of the wrench functions it must be connected to a PC with operating system WINDOWS XP or above.
vuoto
ELECTRONICTORQUEWRENCHES,TORCOTRONIC
SOCKET RATCHETS FOR TORQUE WRENCHES
811G
Orig. Gedore
Sockets with built-in ratchet head to be used in combination with torque wrenches for controlled
clockwise tightening. Square female drive on one extremity, square male drive on the other
extremity. In CHROME-VANADIUM steel.
Drive inch 1/4 3/8 1/2 3/4 1
Overall height mm 21 28 35 53 63
Ø mm 24 35 46 65 73
Supplier code..................... 754-00 754-01 754-02 754-04 754-06
811G Each 110,00 115,00 148,00 217,00 563,00
Socket ratchets for counter clockwise torque wrenches on request.
vuoto
SOCKETRATCHETSFOR TORQUEWRENCHES
811GA
new
Prod. SCU
Sockets with built-in ratchet head with reversible knurled nut for use RIGHT and LEFT of torque
wrenches. In CHROME-VANADIUM steel.
Drive inch 1/2 3/4
Overall height mm 55 90
Ø mm 37 60
811GA Each 108,00 324,00
vuoto
SOCKETRATCHETSFOR TORQUEWRENCHES
PRECISION TORQUE MULTIPLIER
811GT
Prod. SCU
Mechanical torque multiplier of the tightening value set by the operator on the torque wrench. ±
5% tolerance. For bi-directional tightening.
Art. 811 GT 1680: with reaction bar.
Art. 811 GT 2700: with reaction foot.
Art. 811 GT 4500: with reaction bar.
Art. 811 GT 6000: with reaction foot and bar.
Art. 811 GT 9500: with reaction foot and bar.
Supplied in case.
Max tightening threshold Nm 1680 2700 3500 4500 6000 9500
Int. panel for dynamometric key inch 1/2 3/4 3/4 1/2 1/2 1/2
Ext. panel for bushes inch 3/4 1 1 1.1/2 1.1/2 1.1/2
Multiplies force 1x 6 5,4 4,5 16 26 26
Drum Ø mm 100 100 108 120 130 184
Overall height mm 106 126 130 200 216 215
Weight Kg 4,9 6,3 7,3 8,3 15,7 30,3
811GT Each 1.230,00 1.400,00 2.790,00 3.950,00 6.870,00 12.880,00
Check the maximum load to choose the right torque multiplier.
vuoto
PRECISIONTORQUEMULTIPLIER
