215 / 1410
215
HOOK VARIABLE SPANNERS
3
Prices in EURO - VAT not included
215
840G
Model with round interchangeable pivots. Burnished finish, in special hardened steel.
Type
3
4
4A 5
6
6A 8
8A 10
Nib Ø
mm 3
4
4
5
6
6
8
8
10
For rings and
locking ring nuts
mm 18/40 18/40 40/80 40/80 40/80 80/125 80/125 125/200 125/200
Overall length
mm 150 150 220 220 220 295 295 405
405
840G Each 34,10 34,10 46,90 46,90 46,90 69,20 69,20 130,00 130,00
Available on request: the same spanners with square connection 1/2"- 3/4"
for use with torque wrenches.
vuoto
Round interchangeable pivots for Art.840G.
Type
3
4 4A 5
6 6A 8 8A 10
Ø
mm 3
4
4
5
6
6
8
8
10
O840G
Each 4,88 4,88 5,48 5,48 5,48 5,48 5,58 8,98 8,98
vuoto
HOOKVARIABLESPANNERS
HOOK SPANNERS
840GE
Prod. SCU
In special steel, hardened. For nuts DIN 6499 D (ER). Zinc finish.
For locking ring Ø
mm
32
35
42
50
63
Size
DIN 16
20
25
32
40
Overall length
mm 163
183
203
253
285
840GE
Each 12,40 13,70 14,10 17,70 22,10
vuoto
HOOKSPANNERS
HOOK SPANNERS FOR DYNAMOMETRIC CLAMPING
840GL
Prod. SCU
Insert type, 1/2" square drive, for operation in combination with a torque wrench. In special steel,
hardened. For DIN 6499 D (ER) ring nut. Zinc finish.
For locking ring Ø
mm
32
42
50
63
Size
DIN 16
25
32
40
Overall length
mm 69
85
85
85
840GL
Each 69,80 71,50 83,10 93,70
vuoto
HOOKSPANNERSFORDYNAMOMETRICCLAMPING
HOOK SPANNERS
840S
Prod. SCU
In special steel.
Matt chromium plated.
Type with square pin. For nuts DIN 1804 and DIN 981.
For rings and locking ring nuts mm
12/14 16/20 22/28 30/32 34/38 40/42 45/50
Overall length
mm 110
110
136
136
170
170
205
840S
Each 6,78 6,78 6,88 6,88 9,08 9,08 11,10
For rings and locking ring nuts mm
52/55 58/65 68/75 80/90 92/95 98/100 105/115
Overall length
mm 205
240
240
280
280
280
320
840S
Each 11,10 13,20 13,20 16,90 16,90 16,90 25,20
For rings and locking ring nuts mm
120/130 135/145 155/165 180/195 205/220 230/245 260/270
Overall length
mm 330
380
380
380
480
570
570
840S
Each 25,20 41,50 41,60 43,30 78,60 101,00 101,00
When stocks are depleted, we will provide size 12/14 e 16/20 with burnished instead of chromated execution.
HOOKSPANNERS
840T
Product description as Art. 840S
Type with round pin. For nuts DIN 1816.
For rings and locking ring nuts mm
12/14 16/20 25/28 30/32 34/36 40/42 45/50
Overall length
mm 110
110
136
136
170
170
205
840T
Each 8,64 8,64 8,04 8,04 10,60 10,60 12,60
For rings and locking ring nuts mm
52/55 58/62 68/75 80/90 95/100 110/115 120/130
Overall length
mm 205
240
240
280
280
320
330
840T
Each 12,60 14,80 14,80 18,80 18,80 27,30 27,30
For rings and locking ring nuts mm
135/145 155/165 180/195
Overall length
mm 380
380
380
840T
Each 44,50 45,10 46,70
Sizes mm 12/14 e 16/20 are running out of stock
HOOKSPANNERS
841G
Orig. Gedore - Art. 40
In CHROME VANADIUM forged steel. Phosphate finish.
Type with square pin. For nuts DIN 1804 and DIN 981.
For rings and locking ring nuts mm
16/20 25/28 30/32 34/36 40/42 45/50 52/55
Overall length
mm 110
135
135
170
170
205
205
841G
Each 13,40 12,50 12,50 13,40 13,40 15,10 15,10
For rings and locking ring nuts mm
58/62 68/75 80/90 95/100 110/115 120/130 135/145
Overall length
mm 240
240
280
280
335
335
385
841G
Each 17,80 17,80 22,30 23,20 32,70 32,70 46,70
For rings and locking ring nuts mm
155/165 180/195 205/220
Overall length
mm 385
465
465
841G
Each 48,80 123,00 123,00
vuoto
