OIL-HYDRAULIC PUNCHERS
2
153
Prices in EURO - VAT not included
OIL-HYDRAULIC PUNCHERS
760GV
Orig. Baudat - Art. 50-036 (Mod. STAMP 10)
Universal type, head separated from hydraulic pump for use also in confined areas. Operating
parts in hardened steel.
Complete with 2 punch holder pins, adapter and spacer.
Punching strength approx. 100 kN (10 t.).
Only complete body without punches and dies and without pump.
Punches Ø by
mm 15,2 to 100
Punches sheet thickness mm 3
Length
mm 114
Weight
Kg
1.6
760GV
Each 749,00
Punches and dies see Art. 760 GL. Spare pins see Art. 0760 GH/1-2.
Spare adapter and spacer see Art. 0760 GH 3 – 0760 GH 4.
vuoto
OIL-HYDRAULICPUNCHERS
OIL-HYDRAULIC PUNCHING MACHINES FOR INOX
760GV 1
INOX
Orig. Baudat - Art. 50-069 (Mod. STAMP8 HD)
Universal type, head separated from hydraulic pump for use also in confined areas. Operating
parts in hardened steel.
Complete with 3 punch holder pins. Punching strength approx. 80 kN (8 t.).
Only complete body without punches and dies and without pump.
Punches Ø by
mm 16,2 to 68
Punches stainless steel sheet thickness mm 3
Length
mm 101
Weight
Kg
1.5
760GV 1
Each 716,00
Punches and dies see Art. 760 GS 3. Spare pins see Art. 0760 GR/3-5-7.
vuoto
OIL-HYDRAULICPUNCHINGMACHINESFOR INOX
OIL-HYDRAULIC PUMPS
760GV 3
Orig. Baudat - Art. 50-182 (Mod. HHP 8) + Art. 50-219
For hand use in confined areas. Operating parts in hardened steel.
Complete with pipe, length 0,5m. Pressure 450 bar.
Pump with tube for Art. 760 GV – 760 GV 1.
Length
mm 240
Weight
Kg
1.1
760GV 3
Each 755,00
vuoto
OIL-HYDRAULICPUMPS
760GV 5
Orig. Baudat - Art. 50-134 (Mod. HFP 12) + Art. 00-117.01
For foot use in high areas up to approx. m. 2 and where both hands are required to be free.
Operating parts in hardened steel. Complete with support plate and pipe length 3,5 m. Pressure
450 bar.
Pump with tube for Art. 760 GV – 760 GV 1.
Length
mm 340
Weight
Kg
2.5
760GV 5
Each 1.260,00
vuoto
OIL-HYDRAULICPUMPS
760GV 8
Orig. Baudat - Art. 50-080 (Mod. HMP 1E) + Art. 50-248
Electric motor type for continuous working.
230 Volt mono-phase current – 50 Hz.
Complete with pipe length 2,5 m and pedal control. Pressure 450 bar.
Pump with tube and pedal for Art. 760 GV – 760 GV 1.
Dimensions
mm 250x140x260
Weight
Kg
8.5
760GV 8
Each 4.320,00
vuoto
OIL-HYDRAULICPUMPS
