SCREW PUNCHES
2
149
Prices in EURO - VAT not included
SCREW PUNCHES
759GA
Prod. SCU
Professional model with 3 penetration drills in hardened steel. Punching is achieved by pre-drilling
a tip and by subsequently tightening the central screw.
Suitable for steel sheeting, aluminium, plastics, leather, rubber, etc.
Steel blade thickness 2mm up to Ø 30.5mm, 3mm up to Ø 54mm.
Aluminium blade thickness 2.5mm up to Ø 30.5, 3.5mm up to Ø 54mm.
For bores Ø
mm
12,5 12,7 15,2 16 18,6 20,4 20,5 22,5 25,4 25,5
For bores
PG -
7
9
-
11 13 -
16 -
-
For bores
ISO 12 -
-
16 -
-
20 -
-
25
Pre-bore Ø
mm 9
9
9
9
9 13 13 13 13 13
Screw Ø
mm 8
8
8
8
8 12 12 12 12 12
759GA
Each 16,90 16,90 17,10 17,60 18,70 19,70 19,70 27,00 27,80 27,80
For bores Ø
mm
28,3 30,5 32,5 35 37 38 40,5 47 50,5 54
For bores
PG 21 -
-
-
29 -
-
36 -
42
For bores
ISO -
-
32 -
-
-
40 -
50 -
Pre-bore Ø
mm 13 13 13 13 13 13 13 22 18 22
Screw Ø
mm 12 12 12 12 12 12 12 20 16 20
759GA
Each 29,60 30,30 32,90 34,30 34,60 34,60 37,70 57,80 59,10 61,40
vuoto
SPARE SCREWS FOR ART. 759 GA.
In hardened steel quality 12.9.
Screw Ø
mm
8
12
16
20
Pitch
1
1,5
1,5
1,5
Length
mm 55
65
75
80
For Art. 759GA Ø
mm 12,5 to 18,6 20,4 to 40,5 50,5
47 and 54
O759GA
Each 5,40
9,46
11,80
14,80
vuoto
SCREWPUNCHES
759GE
Professional model with 3 penetration drills in special hardened steel, with ball bearing screws
which substantially reduce your manual working time. Punching is achieved by pre-drilling a tip
and by subsequently tightening the central screw.
Suitable for steel sheeting, aluminium, plastics, leather, rubber, etc.
Steel blade thickness 2mm up to Ø 30.5mm, 3mm up to Ø 54mm.
Aluminium blade thickness 2.5mm up to Ø 30.5, 3.5mm up to Ø 54mm.
For bores Ø
mm
12,5 12,7 15,2 16 18,6 20,4 20,5 22,5 25,4 25,5
For bores
PG -
7
9
-
11 13 -
16 -
-
For bores
ISO 12 -
-
16 -
-
20 -
-
25
Pre-bore Ø
mm 9
9
9
9
9 13 13 13 13 13
Screw Ø
mm 8
8
8
8
8 12 12 12 12 12
759GE
Each 22,10 22,10 22,40 22,80 23,90 24,80 24,80 32,70 33,40 33,40
For bores Ø
mm
28,3 30,5 32,5 35 37 38 40,5 47 50,5 54
For bores
PG 21 -
-
-
29 -
-
36 -
42
For bores
ISO -
-
32 -
-
-
40 -
50 -
Pre-bore Ø
mm 13 13 13 13 13 13 13 22 18 22
Screw Ø
mm 12 12 12 12 12 12 12 20 16 20
759GE
Each 35,30 36,10 38,60 40,10 40,30 40,30 43,40 69,30 70,60 72,80
vuoto
SPARE SCREWS WITH BEARINGS FOR ART. 759 GE.
In hardened steel quality 12.9.
Screw Ø
mm
8
12
16
20
Pitch
1
1,5
1,5
1,5
Length
mm 55
65
75
80
For Art. 759GE Ø
mm 12,5 to 18,6 20,4 to 40,5
50,5
47 and 54
O759GE
Each 11,70
16,10
20,70
26,80
vuoto
SCREWPUNCHES
ASSORTED PUNCHES
759GM
Prod. SCU
Suitable for installers. Features in accordance with Art. 759 GA, comes in a practical, sturdy,
plastic casing.
Contents:
6 screwless punches Ø 12.5 (ISO 12) - 16 (ISO 16) - 20.5 (ISO 20) - 25.5 (ISO 25) - 32.5 (ISO
32) - 40.5 (ISO 40) mm
2 screws Art. O759 GA 8 - 12
759GM
Each 143,00
