ASSORTED PUNCHES
2
150
Prices in EURO - VAT not included
759GP
Product description as Art. 759GM
Contents:
6 screwless punches Ø 12.7 (PG 7) - 15.2 (PG 9) - 18.6 (PG 11) - 20.4 (PG 13) - 22.5 (PG 16) -
28.3 (PG 21) mm
2 screws Art. O759 GA 8 - 12
759GP
Each 120,00
vuoto
ASSORTEDPUNCHES
SCREW PUNCHES
760GF
Prod. SCU
Industrial type with 3 hardened steel penetration tips. Punching is obtained through a tipped pre-
hole and later central screwing.>br>Suitable for steel, aluminium, plastic, leather, rubber, etc.
2 mm thick sheet steel up to Ø 27 mm, 3 mm up to Ø 60 mm
The thickness of stainless steel sheet (V2) 1 mm up to Ø 27 mm, 1.5 mm up to Ø 60 mm. CR The
thickness of aluminum sheet, plastics, etc. Ø 4 mm for all.
For bores Ø
mm
12,7 14 15,2 16 17 18 18,6 19 20 20,4 21 22 22.5 23 24 25
Pre-bore Ø
mm 10 10 12 12 12 12 12 12 12 12 12 12 12 12 12 12
Screw Ø
mm 8
8
10 10 10 10 10 10 10 10 10 10 10 10 10 10
760GF
Each 29,10 29,10 29,10 29,10 31,10 31,10 32,60 32,60 32,60 32,60 32,60 35,70 35,70 35,70 35,70 39,10
For bores Ø
mm
26 27 28,3 29 30 31 32 33 34 35 36 37 38 39 40 41
Pre-bore Ø
mm 12 12 14,5 14,5 14,5 14,5 14,5 14,5 14,5 14,5 14,5 14,5 14,5 14,5 14,5 20
Screw Ø
mm 10 10 12 12 12 12 12 12 12 12 12 12 12 12 12 16
760GF
Each 39,10 39,10 39,10 43,40 43,40 43,40 43,40 50,10 50,10 50,10 50,10 50,10 50,10 68,50 68,50 68,50
For bores Ø
mm
42 43 44 45 46 47 48 49 50 51 52 53 54 55 60
Pre-bore Ø
mm 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20
Screw Ø
mm 16 16 16 16 16 16 16 16 16 16 16 16 16 16 16
760GF
Each 74,70 74,70 74,70 81,30 81,30 81,30 89,20 89,20 89,20 97,80 97,80 97,80 106,00 106,00 131,00
SPARE SCREWS FOR ART. 760 GF. In hardened steel.
Screw Ø
mm
8
10
12
16
Pitch
1
1
1,5
1,5
For Art. 759GF Ø
mm 12,7 to 14 15,2 to 27 28,3 to 40 41 to 60
O760GF
Each 1,30
2,04
2,46
3,34
SCREWPUNCHES
ASSORTED PUNCHES
760GFA
760GFB
Prod. SCU
Suitable for installers. Same features as Art. 760 GF, in practical, rugged case of synthetic
material.
Contents:
6 screwless punches Ø 15.2-18.6-20.4-22.5-28.3-32mm
2 screws supplied Art. O760 GF 10 - 12
With countersink and grease
760GFA
Each 319,00
vuoto
Product description as Art. 760GFA
Contents:
8 screwless punches Ø 15.2-18.6-20.4-22.5-28.3-37-47-54mm
3 screws supplied Art. O760 GF 10 - 12 - 16
With countersink and grease
760GFB
Each 526,00
vuoto
ASSORTEDPUNCHES
SCREW PUNCHES
760GFE
new
INOX
Prod. SCU
Type with 2 tips, especially designed for drilling plates made of stainless steel (AISI 304), with
thickness up to mm 4. Special treated steel; finely tuned surfaces of punches and dies for easier
penetration. Screws made of steel, grade 12.9.
For bores Ø
mm
12,7 15,2 16,5 18,6 20,4 22,5 25,4 28,3
Pre-bore Ø
mm 10
12
12
12
12
12
12 14,5
Screw Ø
mm 8
10
10
10
10
10
10
12
760GFE
Each 32,30 32,30 34,10 37,10 37,10 39,80 44,90 44,90
For bores Ø
mm
32 32,5 35
37 40,5 47 50,5 54
Pre-bore Ø
mm 14,5 14,5 14,5 14,5 20
20
20
20
Screw Ø
mm 12
12
12
12
16
16
16
16
760GFE
Each 48,40 55,60 55,60 56,40 74,40 76,20 90,50 110,00
To spare screws for punching machines Art. 760 GFE see Art. O760 GF mm 8-10-12-16.
On request are available the same punching screw with bearing.
