Prices in EURO - VAT not included
1257
HSS TAPS AND DIES
13
9404GF
UNF
HSS
HAND TAPS – HSS steel. RIGHT-HAND USE.
UNF American Thread. DIN 2181-ANSI-B1-1. Tolerance H6.
2pcs set.
Thread UNF
Nr. 6 Nr. 8 Nr. 12
Threads per inch
Nr
40
36
28
9404GF
Per series 31,70 31,70 31,70
For similar hand tap sets see Art. 9130 G.
Product running out of stock
vuoto
HSSTAPSANDDIES
9404GR
NPT
HSS
SHORT HAND/MACHINE TAPS. Made from HSS steel. RIGHT-HAND USE.
NPT American conical thread, taper 1:16. ANSI-B2.1.
For threads
inch
1/8
1/4
3/8
1/2
3/4
1
1.1/4
Threads per inch
Nr
27
18
18
14
14
11,5
11,5
Overall length
mm 54
62
65
79
83
95
102
Thread length
mm 19
27
27
35
35
44
44
9404GR
Each 41,10 45,70 59,00 78,20 108,00 161,00 279,00
vuoto
HSSTAPSANDDIES
9404GS
BSPT
HSS
SHORT HAND/MACHINE TAPS. Made from HSS steel. RIGHT-HAND USE.
BSPT conical gas thread, taper 1:16.
For threads
inch
1/8
1/4
3/8
1/2
3/4
1
1.1/4
Threads per inch
Nr
28
19
19
14
14
11
11
Overall length
mm 59
67
75
87
96
109
119
Thread length
mm 15
19
21
26
28
33
36
9404GS
Each 50,10 57,10 69,20 89,40 121,00 175,00 283,00
vuoto
HSSTAPSANDDIES
9405GA
M
HSS
HSS MACHINE TAPS. RIGHT-HAND USE.
Reinforced shank, correct chamfer for through holes.
M Coarse Metric Thread. DIN 371 B. Tolerance H6.
For threads
mm
3
4
5
6
8
10
Pitch
mm 0,5
0,7
0,8
1
1,25
1,5
9405GA
Each 7,98
7,98
7,98
8,52 10,40 11,60
vuoto
HSSTAPSANDDIES
9405GB
M
HSS
Product description as Art. 9405GA
Reduced shank, correct chamfer for through holes.
M Coarse Metric Thread. DIN 376 B. Tolerance H6.
For threads
mm
3
4
5
6
8
10
12
Pitch
mm 0,5
0,7
0,8
1
1,25
1,5
1,75
9405GB
Each 13,00 13,30 13,60 8,98 15,10 17,80 13,50
For threads
mm
14
16
18
20
22
24
Pitch
mm 2
2
2,5
2,5
2,5
3
9405GB
Each 16,70 19,70 27,10 28,20 34,20 37,70
vuoto
HSSTAPSANDDIES
9405GBR
M
HSS
Product description as Art. 9405GA
Reduced shank, short chamfer for through and blind holes.
Thread: Coarse Metric M. DIN 376 C. Tolerance H6.
For threads
mm
10
12
20
22
24
Pitch
mm 1,5
1,75
2,5
2,5
3
9405GBR
Each 16,10 19,50 40,80 49,30 54,30
For similar machine tap sets see Art. 9212 G.
Product running out of stock
vuoto
HSSTAPSANDDIES
9405GD
M
HSS
Product description as Art. 9405GA
Type with through shank, right-hand 15° spiral flute for blind holes.
Thread: Coarse metric thread M. DIN 376 C. Tolerance H6.
For threads
mm
3
6
18
20
22
Pitch
mm 0,5
1
2,5
2,5
2,5
9405GD
Each 14,80 15,60 46,70 49,80 60,70
For similar machine tap sets see Art. 9232 G.
Product running out of stock
vuoto
HSSTAPSANDDIES
9405GE
M
HSS
Product description as Art. 9405GA
Reinforced shank, 35° spiral flute for deep blind holes.
M Coarse Metric Thread. DIN 371 C. Tolerance H6.
For threads
mm
3
4
5
6
8
10
Pitch
mm 0,5
0,7
0,8
1
1,25
1,5
9405GE
Each 9,70
9,70
9,70 10,20 11,60 13,50
