EXTRA-LONG DRILLS FOR METALS, RIGHT-HAND ROTATION
13
8496G
HSS
Orig. Hartner - Art. 81640
Product description as Art. 8492G
Cylindrical shank.
Ø
mm
3,5
4
4,5
5
5,5
6
6,5
Overall length
mm 265
280
295
315
330
330
350
Helix length
mm 180
190
200
210
225
225
235
8496G
Each 39,80 38,80 48,30 47,30 50,40 53,10 57,30
Ø
mm
7
7,5
8
8,5
9
9,5*
10
Overall length
mm 370
370
390
390
410
410
430
Helix length
mm 250
250
265
265
280
280
295
8496G
Each 74,30 93,40 86,10 109,00 117,00 150,00 138,00
Ø
mm
10,5*
11,5
12
12,5
13
Overall length
mm 430
455
480
480
480
Helix length
mm 295
310
330
330
330
8496G
Each 163,00 177,00 188,00 185,00 188,00
* Sizes running out of stock
vuoto
EXTRA-LONGDRILLSFORMETALS,RIGHT-HANDROTATION
SOLID CARBIDE TWIST DRILLS, HIGH-PERFORMANCE, RIGHT-HAND ROTATION
8497GA
HARTMETALL
TiAIN
Prod. SCU - Orig. M.D. DRILLS - Art. 13880/89413
Particular sharpening and special web thinning ensure max drilling parameters, precise hole
alignment, minimum diameter tolerances and good finishing of the hole surface. Suitable for high-
precision and high-performance machines. For building and case hardening steel, steel cast iron,
quenched and tempered steel, alloy steel with breaking load up to R 1200 N/sqmm, carbonium
steel and aluminium alloys with high silicium content.
DIN 6537. 140 ° cutting angle. Extra short model for drilling depths 3 x D. Cylindrical drive.
DIN 6536 HA compliant. TIALN treatment.
Ø
mm
3
3,3 3,5
4
4,2 4,5 4,8
5
5,5 5,8
6
6,5 6,8
7
7,5
Overall length
mm 62
62
62
66
66
66
66
66
66
66
66
79
79
79
79
Helix length
mm 20
20
20
24
24
24
28
28
28
28
28
34
34
34
41
Drive Ø
mm 6
6
6
6
6
6
6
6
6
6
6
8
8
8
8
Drive length
mm 36
36
36
36
36
36
36
36
36
36
36
36
36
36
36
8497GA
Each 39,10 39,10 39,10 39,10 39,10 39,10 39,10 39,10 39,10 39,10 39,10 39,10 39,10 39,10 39,10
Ø
mm
8
8,5
9
9,5
10 10,2 10,5 11 11,5 12 12.5 13
Overall length
mm 79
89
89
89
89 102 102 102 102 102 107 107
Helix length
mm 41
47
47
47
47
55
55
55
55
55
60
60
Drive Ø
mm 8
10
10
10
10
12
12
12
12
12
14
14
Drive length
mm 36
40
40
40
40
45
45
45
45
45
45
45
8497GA
Each 39,10 43,30 43,30 43,30 43,30 65,10 65,10 65,10 65,10 65,10 86,60 86,60
vuoto
SOLIDCARBIDETWISTDRILLS,HIGH-PERFORMANCE,RIGHT-HANDROTATION
8497GE
HARTMETALL
TiAIN
Prod. SCU - Orig. M.D. DRILLS - Art. 13884/89414
Product description as Art. 8497GA
DIN 6537. 140 ° cutting angle.
Short model for drilling depths 5 x D.
Cylindrical drive. DIN 6536 HA compliant.
TIALN treatment.
Ø
mm
3
3,5
4
4,5
5
5,5
6
6,5
7
8
8,5
9
10 11 12 13
Overall length
mm 66 66 74 74 82 82 82 91 91 91 103 103 103 118 118 124
Helix length
mm 28 28 36 36 44 44 44 53 53 53 61 61 61 71 71 77
Drive Ø
mm 6
6
6
6
6
6
6
8
8
8
10 10 10 12 12 14
Drive length
mm 36 36 36 36 36 36 36 36 36 36 40 40 40 45 45 45
8497GE
Each 44,10 44,10 44,10 44,10 44,10 44,10 44,10 45,40 45,40 45,40 49,60 49,60 49,60 74,10 74,10 97,80
vuoto
SOLIDCARBIDETWISTDRILLS,HIGH-PERFORMANCE,RIGHT-HANDROTATION
8497GL
HARTMETALL
TiAIN
Prod. SCU - Orig. M.D. DRILLS - Art. 13886/89411
Product description as Art. 8497GA
DIN 6537. 140 ° cutting angle.
Short model for drilling depths 5 x D.
Forced lubrication through internal cooling channels.
Cylindrical drive.
DIN 6536 HA compliant.
TIALN treatment.
Ø
mm
4
4,5
5
5,5
6
6,5
7
8
8,5
9
10
11
12
13
Overall length
mm 74
74
82
82
82
91
91
91 103 103 103 118 118 124
Helix length
mm 36
36
44
44
44
53
53
53
61
61
61
71
71
77
Drive Ø
mm 6
6
6
6
6
8
8
8
10
10
10
12
12
14
Drive length
mm 36
36
36
36
36
36
36
36
40
40
40
45
45
45
8497GL
Each 67,80 67,80 67,80 67,80 67,80 75,50 75,50 75,50 86,60 86,60 86,60 126,00 126,00 169,00
vuoto
SOLIDCARBIDETWISTDRILLS,HIGH-PERFORMANCE,RIGHT-HANDROTATION
