LONG DRILLS FOR METALS, RIGHT-HAND ROTATION
13
Ø
mm
6,6 6,7*
6,8 6,9
7 7,1*
7,2*
7,3*
7,4*
7,5 7,6*
7,7*
7,8 7,9*
8 8,2*
Overall length
mm 148 148 156 156 156 156 156 156 156 156 165 165 165 165 165 165
Helix length
mm 97 97 102 102 102 102 102 102 102 102 109 109 109 109 109 109
8487G
Each 35,10 41,40 36,70 39,80 32,90 44,60 52,60 46,70 55,20 40,90 52,60 59,50 61,60 62,70 34,50 54,20
Ø
mm
8,3 8,4*
8,6 8,7 8,8 8,9*
9*
9,1*
9,2*
9,3*
9,4*
9,5*
9,6*
9,7 9,8 9,9*
Overall length
mm 165 165 175 175 175 175 175 175 175 175 175 175 184 184 184 184
Helix length
mm 109 109 115 115 115 115 115 115 115 115 115 115 121 121 121 121
8487G
Each 64,80 66,90 66,90 62,70 73,30 77,50 45,10 78,60 82,80 82,80 79,60 63,70 88,10 93,40 94,50 96,60
Ø
mm
10 10,5 11 11,5*
Overall length
mm 184 184 195 195
Helix length
mm 121 121 128 128
8487G
Each 66,90 89,20 103,00 126,00
Up to Ø 6.7mm in 10pcs packing units. - * Sizes running out of stock
vuoto
LONGDRILLSFORMETALS,RIGHT-HANDROTATION
8490G
HSS
TIN
Orig. Hartner - Art. 84418
DIN 340. Type N. HSS-TIN. Cutting angle 118°. LONG pattern.
Sharpening according to DIN 1414, form N. TIN-treated surface.
For steel up to R 900/sqmm, cast iron, spheroidal cast iron, aluminium and short-chip aluminium
alloys, bronze, brass.
Cylindrical shank.
Ø
mm
1
1.5
2
2,2*
2,5 2,8
3
3,3 3,8
4
4,2 4,5*
5
5,2*
5,5
Overall length
mm 56
70
85
90
95 100 100 106 119 119 119 126 132 132 139
Helix length
mm 33
45
56
59
62
66
66
69
78
78
78
82
87
87
91
8490G
Each 19,70 16,80 14,80 17,40 14,80 18,10 15,10 15,90 17,20 16,40 16,40 17,10 18,10 21,10 19,70
Ø
mm
5,8*
6
6,2*
6,8*
7
7,2 7,5*
7,8
8
8,2*
8,5 8,8*
9
9,2*
9,5
Overall length
mm 139 139 148 156 156 156 156 165 165 165 165 175 175 175 175
Helix length
mm 91
91
97 102 102 102 102 109 109 109 109 115 115 115 115
8490G
Each 22,10 20,10 37,10 37,50 34,40 43,70 36,50 43,70 36,10 40,60 39,60 47,30 40,60 54,50 48,80
Ø
mm
9,8*
10 10,5* 10,8* 11,5 12
Overall length
mm 184 184 184 195 195 205
Helix length
mm 121 121 121 128 128 134
8490G
Each 57,60 42,70 43,70 66,80 64,70 62,70
Up to Ø 6.2mm in 10pcs packing units. - * Sizes running out of stock
vuoto
LONGDRILLSFORMETALS,RIGHT-HANDROTATION
EXTRA-LONG DRILLS FOR METALS, RIGHT-HAND ROTATION
8492G
HSS
Orig. Hartner - Art. 81440
DIN 1869. Type FN. HSS. Cutting angle 130°.
EXTRA-LONG pattern.
For steel and steel cast iron up to R 1000 N/sqmm, spheroidal cast iron, aluminium and
aluminium alloys, brass and bronze.
Cylindrical shank.
Ø
mm
2
2,5
3
3,2
3,5
4
4,2
4,5
5
5,1
5,2
5,5
6
Overall length
mm 125
140
150
155
165
175
175
185
195
195
195
205
205
Helix length
mm 85
95
100
105
115
120
120
125
135
135
135
140
140
8492G
Each 18,80 18,80 20,90 26,00 20,90 21,80 29,20 24,50 24,50 39,30 38,80 27,60 26,60
Ø
mm
6,5
7
7,5
8
8,5
9
9,5
10
10,5
11
11,5
12
Overall length
mm 215
225
225
240
240
250
250
265
265
280
280
295
Helix length
mm 150
155
155
165
165
175
175
185
185
195
195
205
8492G
Each 37,70 38,80 46,70 47,80 61,60 66,90 78,60 69,10 121,00 92,40 112,00 106,00
vuoto
EXTRA-LONGDRILLSFORMETALS,RIGHT-HANDROTATION
8494G
HSS
Orig. Hartner - Art. 81540
Product description as Art. 8492G
Cylindrical shank.
Ø
mm
3
3,5
4
4,5
5
5,5
6
6,5
Overall length
mm 190 210 220 235 245 260 260 275
Helix length
mm 130 145 150 160 170 180 180 190
8494G
Each 28,70 32,40 30,30 34,10 32,90 40,90 39,30 47,30
Ø
mm
7
7,5
8
8,5
9
9,5
10 10,2
Overall length
mm 290 290 305 305 320 320 340 340
Helix length
mm 200 200 210 210 220 220 235 235
8494G
Each 49,40 71,10 57,30 90,20 88,10 107,00 94,50 144,00
Ø
mm
10,5 11 11,5 12 12,5 13
Overall length
mm 340 365 365 375 375 375
Helix length
mm 235 250 250 260 260 260
8494G
Each 142,00 133,00 156,00 151,00 160,00 164,00
vuoto
EXTRA-LONGDRILLSFORMETALS,RIGHT-HANDROTATION
