AIRVISION COMBINATION AIR TREATMENT UNITS
10
AIRVISION COMBINATION AIR TREATMENT UNITS
3462GA
Orig. Ewo - Art. 445-7445
AIRVISION FILTERS FOR COMPRESSED AIR
Modular model with small dimensions, to be used alone or as a spare part for combinations
Art. 3462 GP-T-V. Supplied with manual drain valve. Polyethylene porous filter 50µm.
Body in metal alloy (zinc/cast iron). Polycarbonated unbreakable glass.
Max operating temperature 50°C.
Drive
inch
1/8
1/4
3/4
Dimensions (A)
mm 40
40
70
Dimensions (B)
mm 120
120
215
Dimensions (E)
mm 25
25
35
3462GA
Each 44,30 44,30 143,00
Standard operating pressure: 6 bar (Atm).
Size inch 3/4 is running out of stock
vuoto
AIRVISIONCOMBINATIONAIRTREATMENTUNITS
3462GE
Orig. Ewo - Art. 444-7444
AIRVISION REGULATORS FOR COMPRESSED AIR
Modular model with small dimensions, to be used alone or as a spare part for combinations
Art. 3462 GP-T-V. Body in metal alloy (zinc/cast iron). Supplied with manometer.
Adjustable from 0.5 to 10 bar (Atm). Max operating temperature 50 °C.
Drive
inch
1/8
1/4
3/4
Dimensions (A)
mm 40
40
70
Dimensions (B)
mm 90
90
145
Dimensions (E)
mm 25
25
41
3462GE
Each 59,30 59,30 191,00
Standard operating pressure: 6 bar (Atm). Spare manometers are supplied on demand.
Size inch 3/4 is running out of stock
vuoto
AIRVISIONCOMBINATIONAIRTREATMENTUNITS
3462GH
Orig. Ewo - Art. 446-7446
AIRVISION LUBRICATORS FOR COMPRESSED AIR
Modular model with small dimensions, to be used alone or as a spare part for combinations
Art. 3462 GP-T. With pilot light to check oil falling.
Body in metal alloy (zinc/cast iron). Polycarbonate unbreakable glass.
Max operating temperature 50 °C.
Drive
inch
1/8
1/4
3/4
1
Dimensions (A)
mm 40
40
70
70
Dimensions (B)
mm 140
140
230
230
Dimensions (E)
mm 50
50
65
65
3462GH
Each 48,30 48,30 147,00 147,00
Standard operating pressure: 6 bar (Atm).
Sizes inch 3/4 and 1 are running out of stock
vuoto
AIRVISIONCOMBINATIONAIRTREATMENTUNITS
3462GP
Orig. Ewo - Art. 450-7450
AIRVISION FILTER-REGULATOR-LUBRICATOR COMBINATIONS
Combination of 3 pieces with the same features of the elements Art. 3462 GA-E-H.
Drive
inch
1/8
1/4
3/4
Dimensions (A)
mm 120
120
210
Dimensions (B)
mm 160
160
274
Dimensions (E)
mm 65
65
100
3462GP
Each 166,00 166,00 509,00
Standard operating pressure: 6 bar (Atm). Spare manometers are supplied on demand.
Size inch 3/4 is running out of stock
vuoto
AIRVISIONCOMBINATIONAIRTREATMENTUNITS
3462GT
Orig. Ewo - Art. 449-7449
AIRVISION FILTER-REGULATOR-LUBRICATOR COMBINATIONS
Combination of 2 pieces with the same features of the elements Art. 3462 GA-E-H.
Drive
inch
1/8
1/4
Dimensions (A)
mm 80
80
Dimensions (B)
mm 160
160
Dimensions (E)
mm 65
65
3462GT
Each 133,00 133,00
Standard operating pressure: 6 bar (Atm). Spare manometers are supplied on demand.
vuoto
