824 / 1410
824
Prices in EURO - VAT not included
824
PORTABLE FLOOR-TYRE INFLATOR-TESTER WITH AIR TANK
10
PORTABLE FLOOR-TYRE INFLATOR-TESTER WITH AIR TANK
3461
Prod. SCU
Portable, handy, floor-tyre inflator. Tank capacity 12l with manual or automatic charge. Inflator with
manometer, rubber hose, nozzle and safety valve set at 7bar. Weight: 10kg.
Equipment complete with charging valve.
3461
Each 341,00
vuoto
Spare gun for Art. 3461.
O3461
Each 30,40
vuoto
PORTABLEFLOOR-TYRE INFLATOR-TESTERWITHAIRTANK
3461G
Orig. Ewo - Art. 350
Portable tester with air-tank, handy and very sturdy.
Tank capacity 6l can be charged up to 16 bar (Atm). Relief valve to protect from overcharge.
Special inside spring in BERYLLIUM/COPPER grants otimal precision testing also for AZOTE
inflation. Can inflate completely 4 car tyres or more if they are to be checked and re-inflated.
Manometer in 20° tilted position for easy reading. Scale plate diameter: 160mm.
Condensation is drained with manual valve. Individually tested.
Easy to use.
Inflation handle with double-nozzle rod. Push buttons on the handle to operate the 3 phases:
Check = Insert the rod in the tyre valve and read the manometer.
Inflation = Push the button (+)
Drainage = Push the button (-).
Manometer range: 0-10 bar (Atm)/0-140 PSI with double-nozzle rod, weight 7.1 kg.
Equipment complete with charging valve.
3461G
Each 1.140,00
Automatic charge.
Air is charged (with idle equipment) by means of a pipe union placed at the end of the carrying handle.
This union between handle and the quick coupling allows automatic charge as far as the necessary operating pressure is reached.
vuoto
PORTABLEFLOOR-TYRE INFLATOR-TESTERWITHAIRTANK
3461GA
Only charging valve for Art. 3461 G.
3461GA
Each 33,40
vuoto
PORTABLEFLOOR-TYRE INFLATOR-TESTERWITHAIRTANK
3461GB
Spare inflator complete with hose for Art. 3461 G.
3461GB
Each 227,00
vuoto
PORTABLEFLOOR-TYRE INFLATOR-TESTERWITHAIRTANK
AIRVISION L COMBINATION AIR TREATMENT UNITS
3461GL
Orig. Ewo - Art. 460
AIRVISION L FILTERS FOR COMPRESSED AIR
Modular model with small dimensions. Supplied with manual drain valve. Polyethylene porous
filter 50µm. Polycarbonate unbreakable glass.
Max operating temperature 50 °C.
Drive
inch 1/4
Dimensions (A)
mm 40
Dimensions (B)
mm 110
Dimensions (E)
mm 11
3461GL
Each 27,30
Standard operating pressure: 6 bar (Atm).
vuoto
Pair of threaded connection reductions from 1/4 to 1/8 inch for all AIRVISION "L" components
from Art. 3461 GL to Art. 3461 GR.
O3461GL
Per pair
2,88
vuoto
AIRVISION LCOMBINATIONAIR TREATMENTUNITS
