825 / 1410
825
Prices in EURO - VAT not included
825
AIRVISION L COMBINATION AIR TREATMENT UNITS
10
3461GM
Orig. Ewo - Art. 461
AIRVISION L REGULATORS COMPRESSED AIR
Modular model with small dimensions. Supplied with manometer. Adjustable from 0.5 to 10 bar
(atm). Max operating temperature 50 °C.
Drive
inch 1/4
Dimensions (A)
mm 40
Dimensions (B)
mm 80
Dimensions (E)
mm 11
3461GM
Each 46,80
Standard operating pressure: 6 bar (Atm). Spare manometers are supplied on demand.
vuoto
AIRVISION LCOMBINATIONAIR TREATMENTUNITS
3461GP
Orig. Ewo - Art. 462
AIRVISION L LUBRICATORS FOR COMPRESSED AIR
Modular model with small dimensions. With pilot light to check oil falling. Polycarbonate
unbreakable glass. Max operating temperature 50 °C.
Drive
inch 1/4
Dimensions (A)
mm 40
Dimensions (B)
mm 135
Dimensions (E)
mm 47
3461GP
Each 30,90
Standard operating pressure: 6 bar (Atm).
vuoto
AIRVISION LCOMBINATIONAIR TREATMENTUNITS
3461GP 3
Orig. Ewo - Art. 465
AIRVISION L FILTER-REGULATOR-LUBRICATOR COMBINATIONS
Combination of 3 pieces with the same features of the elements Art. 3461 GL-M-P. Adjustable
from 0.5 to 10 bar (Atm).
Drive
inch 1/4
Dimensions (A)
mm 120
Dimensions (B)
mm 170
Dimensions (E)
mm 69
3461GP 3
Each 110,00
Standard operating pressure: 6 bar (Atm). Spare manometers are supplied on demand.
vuoto
AIRVISION LCOMBINATIONAIR TREATMENTUNITS
3461GP 5
Orig. Ewo - Art. 464
AIRVISION L FILTER-REGULATOR-LUBRICATOR COMBINATIONS
Combination of 2 pieces with the same features of the elements Art. 3461 GL-M-P. Adjustable
from 0,5 to 10 bar (Atm).
Drive
inch 1/4
Dimensions (A)
mm 80
Dimensions (B)
mm 178
Dimensions (E)
mm 79
3461GP 5
Each 94,50
Standard operating pressure: 6 bar (Atm). Spare manometers are supplied on demand.
vuoto
AIRVISION LCOMBINATIONAIR TREATMENTUNITS
3461GR
Orig. Ewo - Art. 463
AIRVISION L FILTER-REGULATOR COMBINATIONS
Combination of 1 piece with the same features of the elements Art. 3461 GL-M.
Drive
inch 1/4
Dimensions (A)
mm 40
Dimensions (B)
mm 160
Dimensions (E)
mm 65
3461GR
Each 58,10
Standard operating pressure: 6 bar (Atm). Spare manometers are supplied on demand.
vuoto
AIRVISION LCOMBINATIONAIR TREATMENTUNITS
