768 / 1410
768
Prices in EURO - VAT not included
768
MAGNETIC SETSQUARES
10
3295E
Orig. Peddinghaus
Fixed type. Sturdy steel sheet body, U-shaped section.
Allows coupling of any shape for easier welding or working without manual holding/fixing.
Positioning them on different sides allows angles of 45° - 90°.
With 2 riveted side holes to allow the magnets to be connected in sets using screws.
With magnet disconnection switch.
Length
mm
95
130
Height
mm 110
150
Diagonal
mm 100
140
Max magnetic force
Kg 31,5 to 36 54 to 63,5
Supplier code ....................
0046000000 0048000000
3295E
Each 108,00
138,00
Magnetic force varies according to the length of the used side.
Size mm 130 is running out of stock
vuoto
MAGNETICSETSQUARES
3295L
Prod. SCU
Adjustable model. Ferrite magnets with high grip.
Allow you to match bodies of any form for convenient processing or welding, without manual
intervention.
Arms tilting from 45° to 90° with references at 60° and 75°.
Max. magnetic force 250 N. Dimensions 115x115x35mm. Weight 1.5 Kg.
3295L
Each 109,00
vuoto
MAGNETICSETSQUARES
SOLDER WIRE
3361GA
Prod. SCU
Solder wire with internal deoxidizer DIN EN 29453 (DIN 8516).
For quick and tough, tin and plub soldering, without acids nor deoxidizers.
Melting temperature: 183 °C - 235 °C.
Alloy 40% of tin. Spools of 1 m approx.
Wire Ø
mm
1,5
2
3361GA
Each 1,64
1,28
vuoto
SOLDERWIRE
3361GB
Solder wire with internal deoxidizer DIN EN 29453 (DIN 8516).
For quick and tough, tin and plub soldering, without acids nor deoxidizers also in electric and
electronic applications. Melting temperature: 183 °C - 190 °C.
Alloy 60% of tin. Spools of 1 m approx.
Wire Ø
mm
1
1,5
2
3361GB
Each 1,64
1,84
1,84
vuoto
SOLDERWIRE
3361GC
Solder wire with internal deoxidizer DIN EN 29453 (DIN 8516).
For quick and tough, tin and plub soldering, without acids nor deoxidizers.
Melting temperature: 183 °C - 235 °C.
Alloy 40% of tin. In package units of 1 kg (corresponding to 4 skeins of kg 0.250).
Wire Ø
mm
1
1,5
2
3
3361GC
Per kg 57,20 57,40 55,50 55,40
vuoto
SOLDERWIRE
3361GL
Solder wire with internal deoxidizer DIN EN 29453 (DIN 8516).
For quick and tough, tin and plub soldering, without acids nor deoxidizers.
Melting temperature: 183 °C - 190 °C.
Alloy 60% of tin. In package units of 1 kg (corresponding to 4 skeins of kg 0.250).
Wire Ø
mm
1
1,5
2
3
3361GL
Per kg 73,30 72,30 71,60 71,40
vuoto
SOLDERWIRE
3361GM
Solder wire with internal deoxidizer DIN EN 29453 (DIN 8516).
For quick and tough, tin and plub soldering, without acids nor deoxidizers also in electric and
electronic applications. Melting temperature: 183 °C - 190 °C.
Alloy 60% of tin. In package units of 1 kg (corresponding to 4 skeins of kg 0.250).
Wire Ø
mm
0,5
0,75
1
1,5
2
3361GM
Per kg 101,00 81,60 73,30 72,30 71,60
vuoto
SOLDERWIRE
