765 Prices in EURO - VAT not included
765
WELDING ELECTRODES
10
3272B
Basic coating type, according to 7018-S1 specification. Suitable for strong welding of iron, steel,
steel alloys etc. for heavy carpentry such as shipbuilding, heavy vehicles etc.. For welding
machines Art. 3270 a 3271 L and high voltage welding machines (70 V min.) In packing units, not
sold separately.
Ø mm 2 2,5 3,25 4
Length mm 300 300 450 450
Cfz. indivisibili pcs 400 250 150 100
Peso conf. Kg 4,8 4,3 6,3 7,2
3272B Per pack 84,90 53,60 67,90 61,70
vuoto
WELDINGELECTRODES
3272E INOX Type with Rutile coating with very low Carbonium level. Suitable for welding INOX, AISI 347 - 321
- 308 - 304L - 304 - 302 - 301. Suitable for welding machines Art. 3270 to 3271 L and high voltage
welding machines (50 V mon.) both with direct and alternate current. In packing units, not sold
separately.
Ø mm 2 2,5 3,25
Length mm 300 300 350
Cfz. indivisibili pcs 230 130 77
Peso conf. Kg 2,6 2,6 2,6
3272E Per pack 122,00 98,10 97,30
vuoto
WELDINGELECTRODES
3272L INOX Titanium-coated model with very low carbon content. Suitable for welding STAINLESS steel AISI
316 - 316L - 202 - 317.
To be used with welding machines Art. 3270 to 3271 L and high voltage welding machines, (min.
50 V) both direct and alternate current. In packing units not sold separately.
Ø mm 2 2,5 3,25
Length mm 300 300 350
Cfz. indivisibili pcs 230 130 77
Peso conf. Kg 2,6 2,6 2,6
3272L Per pack 137,00 118,00 115,00
vuoto
WELDINGELECTRODES
3272R INOX Basic-coated model with low carbon content. Suitable for welding STAINLESS steel AISI 309 -
309S - 310 310S with standard steel in dissimilar welding.
To be used with welding machines Art. 3270 to 3271 L and high voltage welding machines, (min.
50 V) both direct and alternate current. In packing units not sold separately.
Ø mm 2,5 3,25
Length mm 300 350
Cfz. indivisibili pcs 140 77
Peso conf. Kg 2,7 2,7
3272R Per pack 179,00 190,00
vuoto
WELDINGELECTRODES
ELECTRODE-HOLDERS
3277
Prod. SCU
Straight type with electrode-holder jaws. Made of heavy brass. Totally insulated.
Cable connection inside the handle. Electrodes may be clamped in any direction. Conform to
European specifications EN 60974-11.
Size 200 350 500 700
Capacity at 60% A 150 200 250 300
For electrodes up to Ø mm 3,2 3,2 5 6,3
Max cable section Ø mm² 25 35 50 70
3277 Each 11,50 15,50 18,40 22,30
vuoto
ELECTRODE-HOLDERS
3277G
Straight type with electrode-holder jaws. Totally insulated. Handle is made of special sintered
material, fire-proof, shatter-proof with high insulating power.
Jaws are externally insulated through a thick protection. Strong spring.
Conform to European specifications EN 60974-11.
Fine max load capacity A 200 300 400 600
For electrodes up to Ø mm 3 4 4 6
3277G Each 14,90 16,70 20,10 24,20
vuoto
Insulated protections for Art. 3277 G.
Fine max load capacity A 200 300 400 600
O3277G Per pair 3,00 4,36 4,36 5,40
vuoto
ELECTRODE-HOLDERS
3277S
Straight type with electrode-holder hole. Totally insulated, including the lever.
Fiber-glass handle and tip with strongly insulated head.
Conform to European specifications EN 60974-11.
Size 300 400 500 600
Capacity at 60% A 150 200 250 300
For electrodes up to Ø mm 3,2 4 5 6,3
Max cable section Ø mm² 25 35 50 70
3277S Each 21,30 24,10 27,20 29,40
vuoto
