Prices in EURO - VAT not included
764
ELECTRODE ARC-WELDING MACHINES
10
ELECTRODE ARC-WELDING MACHINES
3269B
IP21
Prod. SCU
Portable electric arc-welding machines, with monophasic alternate current. Conform to European
specifications EN 60974-6/ EN 60974-10.Forced air-cooling. Continuous current control by
means of a graduated scale knob. Thermostatic protection against overloads. Voltage 230-400 V
- 50Hz. Loadless voltage 48 V. Class H insulation. Protection IP 21. For rutile-coated electrode
welding of soft steels, iron, steel plates etc.
Max absorbed power by
kW 2,5 to 4,5
Min÷max electrode
mm 2-4
Min/max current regulation
A
55-150
Weight approx.
Kg
19
Dimensions
mm 420x280x330h
3269B
Each 294,00
For electrode holders, clamps and connectors see from Art. 3277 to 3284.
For kit cables, clamps, yoke, helmet etc. see Art. 3290.
Product running out of stock
vuoto
ELECTRODEARC-WELDINGMACHINES
INVERTER WELDING MACHINES
3271A
Prod. SCU
Professional portable electric welding machines, monophasic alternate current. Conform to
European specifications EN 60974-1/EN 60974-10. Forced-air cooling for non-stop use.
Continuous current control by means of a graduated scale knob. Automatic protection against
overheating with automatic reset.
Voltage 230 V - 50/60 Hz. SCHUKO plug. Loadless voltage 70V. Class H insulation. Suitable for
welding with all kinds of electrodes (except those containing cellulose). Supplied with transport
case, helmet with adiactinic glass, welding cap and brushes, electrode holder andearth clamp
with 3 + 2m cable cross section 16mm² and joints Ø 25mm.
Max absorbed power by
kW 2
Min÷max electrode
mm 1,6-3,2
Min/max current regulation
A
10-140
Weight approx.
Kg
4,5
Dimensions
mm 130x270x225h
3271A
Each 637,00
vuoto
INVERTERWELDINGMACHINES
3271E
Professional electric welding machines, with monophasic alternate current. Compliant with
European specifications EN 60974-1/ EN 60974-10. Forced air-cooling for continuous use.
Continuous electronic current control by means of a graduated scale knob. Automatic protection
against overheating with automatic reset.
Voltage 230 V - 50/60 Hz. SCHUKO type plug. Loadless voltage 80 V. Insulation class H. For
welding using all types of electrode (excluding those containing cellulose). Supplied with helmet
with adiactinic glass, welding cap and brushes, electrode holder and earth clamp with 3 + 2m
cable cross section 16mm² and joints Ø 25mm.
Max absorbed power by
kW 3,5
Min÷max electrode
mm 1,6-4
Min/max current regulation
A
10-160
Weight approx.
Kg
4,8
Dimensions
mm 135x370x260h
3271E
Each 781,00
The technical characteristics of Art. 3271 A - E
are subject to possible changes by the manufacturer.
vuoto
INVERTERWELDINGMACHINES
WELDING ELECTRODES
3272A
Prod. SCU
Rutile-coated type, according to E 6013 specification. Suitable for welding iron, building steel,
pressurized reservoirs etc. Suitable for welding machines Art. 3269 B a 3271 L and portable
welding machine with standard voltage (45 V min.). In packing units, not sold separately.
Ø
mm
1,5
2
2,5
3,25
4
Length
mm 300
300
300
450
450
Cfz. indivisibili
c.capcs
290
400
250
150
100
Peso conf.
c.caKg
2,2
4,3
4,2
6,9
6,7
3272A
Per pack 46,40 45,20 31,70 55,40 52,40
