715 / 1410
715
Prices in EURO - VAT not included
715
PILLAR DRILLS WITH MAGNETIC SUPPORT
9
3078GL
Type with a 30° revolving basement, 20mm longitudinally adjustable.
Sturdy and stable manufacture, with magnetic support for vertical, horizontal and upside down
use. 230 V-50 Hz monophase motor with overload safety switch included. Equipped with locking
device to avoid accidental start-up before the magnet is installed. Reverse rotation for tapping
operation. Automatic lubrication. Weldon shaft Ø 19mm and CM 3. In practical transport case.
Four speed-model
Boring capacity with cutting mills
mm 12 to 75
Threading capacity
M
3 to 14
Bores with tips with cyl. drive up to mm
16
Bores with tips with drive CM3 up to mm 31,75
Magnet traction force
N
22500
Magnet dimensions
mm 200x100
Power
W 1800
No-load speed
rev/min 210/270/410/530
Height
mm
550
Max cutting depth
mm
100
Weight
Kg
27
3078GL
Each 2.390,00
For drilling machine electromagnetic stands see Art. 1682.
vuoto
CM 3 shaft adapter complete with three-jaw chuck, opening 3-16mm.
O3078GL
Each 34,60
vuoto
CM 3/Weldon 32 adapter for core drills from Ø 66mm.
O3078GLA
Each 165,00
vuoto
Socket holder chuck CM 3 for tap holder sockets from M 3 to 14.
O3078GLB
Each 251,00
vuoto
Tap holder socket for taps DIN 371/376
Size
1
2
3
4
5
6
7
For taps
M 3
4
5-6
8
10
12
14
Drive Ø
mm 3,5
4,5
6
8
10
9
11
O3078GLE
Each 73,50 73,50 73,50 73,50 73,50 73,50 73,50
vuoto
PILLARDRILLSWITHMAGNETICSUPPORT
BATTERY MAGNETIC-STAND DRILLING MACHINES
3078GP
37V
Prod. SCU
Sturdy body, compact, stable, with magnetic support for vertical, horizontal or upside down use.
HIGH NUMBER OF HOLES PER CHARGE.
Equipped with a very powerful LITHIUM battery, removable and rechargeable in a short time (60
min). 230 V battery charger. With a device that allows the magnet to remain in traction even when
the battery is low. Automatic lubrication. Weldon connection Ø 19 mm. In practical carry cases.
Boring capacity with cutting
mill
mm 12 to 36
Bores with tip up to
mm
13
Magnet traction force
N
10000
Magnet dimensions
mm 160x80
Power
W 1500
No-load speed
rev/min
510
Battery voltage:
Volt
37-7,6 Ah Li
Height
mm 480/590
Max cutting depth
mm
55
Weight
Kg
15
3078GP
Each 2.650,00
vuoto
Spare charger for Art. 3078 GP.
O3078GP 1
Each 388,00
vuoto
Spare battery for Art. 3078 GP.
O3078GP 2
Each 898,00
vuoto
BATTERYMAGNETIC-STANDDRILLINGMACHINES
