713 / 1410
713
Prices in EURO - VAT not included
713
CORE DRILLS
9
3077GM
HSS-Co
Made from HSS-M2 steel, CBN ground.
Cutting edges for right-hand rotation. To be used on pillar drills, magnetic or normal, with direct
Weldon shank ø 19mm. Particularly suitable for drilling I-beams, large steel plates, steel, light
alloys, etc. Special cut geometry allows to increase drilling speed, much higher than that of
conventional helical bits. The core drills are supplied with integral shank, without pilot bits.
Suitable for use on pillar drills with magnet Art. 3078 G-3078 GA-3078 GE-3078 GL-3078 GP.
Cutting depth 50mm
Ø
mm
12
13
14
15
16
17
18
3077GM
Each 33,30 33,70 33,70 35,10 36,30 37,60 39,40
Ø
mm
19
20
21
22
23
24
25
3077GM
Each 39,80 42,80 45,10 46,30 48,90 49,70 51,90
Ø
mm
26
27
28
29
30
31
32
3077GM
Each 53,20 56,60 57,50 59,70 62,20 72,60 78,70
Ø
mm
33
34
35
36
37
38
39
3077GM
Each 81,30 94,20 99,10 119,00 121,00 122,00 126,00
Ø
mm
40
41
42
43
44
45
46
3077GM
Each 127,00 127,00 136,00 142,00 146,00 148,00 148,00
Ø
mm
47
48
49
50
51
52
53
3077GM
Each 154,00 160,00 162,00 171,00 175,00 180,00 191,00
Ø
mm
54
55
56
57
58
59
60
3077GM
Each 200,00 205,00 209,00 216,00 222,00 257,00 277,00
Ø
mm
61
64
3077GM
Each 327,00 352,00
Crown mills Art. 3077 GM 61 to 75 mm Weldon 32 coupling
for magnetic column drills Art. 3078 GL available on request.
Sizes mm 61 and 64 are running out of stock
vuoto
Pilot bits 6.35x105mm, for Art. 3077 GM.
O3077GP 1
Each 9,62
vuoto
COREDRILLS
3077GT
HARTMETALL
Type with hard metal teeth.
Cutting edges for right-hand rotation. To be used on pillar drills, magnetic or normal, with direct
Weldon shank ø 19mm. Particularly suitable for drilling hard materials. Special cutting geometry
allows extended tool life. The core drills are supplied with integral shank, without pilot bits.
Suitable for use on pillar drills with magnet Art. 3078 G-3078 GA-3078 GE-3078 GL-3078 GP.
Cutting depth 30mm.
Ø
mm
16
17
18
19
20
21
22
3077GT
Each 80,60 80,60 80,60 80,60 80,60 85,10 85,10
Ø
mm
23
24
25
26
27
28
29
3077GT
Each 85,10 85,10 85,10 91,30 91,30 97,80 97,80
Ø
mm
30
31
32
33
34
35
40
3077GT
Each 97,80 105,00 105,00 111,00 111,00 111,00 135,00
Ø
mm
45
50
3077GT
Each 171,00 175,00
vuoto
Pilot bits length 90mm, for Art. 3077 GT.
Size
1
2
Ø
mm 6,35
8
For cutting mills Ø
mm 16-17 18 to 50
O3077GT
Each 7,82 11,40
vuoto
COREDRILLS
MULTI-PURPOSE ELECTRIC DRILLING MACHINES
3078B
Prod. SCU
Professional model suitable for drilling with core bits, hole saws, drill tips (in rotation only) and for
tapping. 230 V single-phase motor with infinitely variable speed control, rotation R+L, joint torque
limiter, electronic overload protection, restart lock that prevents the automatic restart of the drill
after an overload. Equipped with additional handle. Rack chuck att. 5/8, opening 3-16 mm.
In case.
Boring capacity with MD crown mills
mm 15 to 30
Boring capacity with MD crown mills and HSS hole saws mm 12 to 60
Bores with tips (only rotation) uo to
mm 20
Bores with MDtips for continuous boring
M 4 to 8
Threads with taps up to
M 12
Absorbed power
W 1300
Performance
W 800
Nominal speed
rev/min 0-2000
No-load speed
rev/min 3400
Weight
Kg
3,4
3078B
Each 1.420,00
vuoto
MULTI-PURPOSEELECTRICDRILLINGMACHINES
