714 / 1410
714
Prices in EURO - VAT not included
714
ELECTRIC TAP MACHINE
9
ELECTRIC TAP MACHINE
3078E
new
Prod. SCU
Professional type for tapping seel and in aluminum, right rotation. 220-240 V single-phase motor
with differentiated speed between the threading phase (slow) and the inversion phase (fast).
Safety function and slightly tilting joint to facilitate the entry of the tap into the hole. Overload
protection. Equipped with additional handle and depth stop for threads in blind holes. Chuck with
locking screw.
In case.
Threading capacity with steel
mm - inch 18 - 9/16
Threading capacity with aluminium mm - inch 16 - 5/8
Absorbed power
W 450
Tapping speed
rev/min
280
Inversion speed
rev/min
680
Weight
Kg
2,7
3078E
Each 994,00
vuoto
ELECTRICTAPMACHINE
PILLAR DRILLS WITH MAGNETIC SUPPORT
3078G
Prod. SCU
Angular-type, feeding through a lever that can be installed on both sides of the drilling machine.
Suitable for drilling in confined areas. Sturdy manufacture, compact and handy, with magnetic
support for vertical, horizontal and upside down use. 230 V-50/60 Hz monophase motor with
overload safety switch included. Equipped with locking device to avoid accidental start-up before
the magnet is installed. Manual lubrication (see Art. 3100 M). Weldon shank Ø 19mm. In practical
transport case.
Single speed.
Boring capacity with cutting
mills
mm 12 to 35
Magnet traction force
N 15000
Magnet dimensions
mm 160x80
Power
W 1100
No-load speed
rev/min 650
Height
mm 200
Max cutting depth
mm 30
Weight
Kg
10
3078G
Each 1.230,00
vuoto
PILLARDRILLSWITHMAGNETICSUPPORT
3078GA
Sturdy manufacture, compact, light, with magnetic support for vertical, horizontal and upside
down use. 230 Volt monophase motor with overload safety switch included. Equipped with locking
device to avoid accidental start-up before the magnet is installed. Automatic lubrication. Weldon
shank Ø 19mm. In practical case.
Single speed.
Boring capacity with cutting mills mm 12 to 35
Bores with tips up to
mm 13
Magnet traction force
N 15000
Magnet dimensions
mm 160x80
Power
W 1100
No-load speed
rev/min 620
Height
mm 400
Max cutting depth
mm 50
Weight
Kg
12
3078GA
Each 1.120,00
vuoto
Adapter complete with three-jaw chuck, opening 1,5-13mm, for drill Art. 3078 GA.
O3078GB
Each 30,80
vuoto
PILLARDRILLSWITHMAGNETICSUPPORT
3078GE
Sturdy manufacture, compact, steady, with magnetic support for vertical, horizontal or upside
down use. 230 V-50 Hz mono-phase motor with overload safety switch included. Equipped with
locking device to avoid accidental start-up before the magnet is installed. Automatic lubrication.
Weldon shank Ø 19mm. In handy case.
Double speed.
Boring capacity with cutting mills mm 12 to 50
Bores with tips up to
mm 16
Magnet traction force
N 32000
Magnet dimensions
mm 200x100
Power
W 1800
No-load speed
rev/min 380/500
Height
mm 495
Max cutting depth
mm 75
Weight
Kg 22,9
3078GE
Each 1.810,00
vuoto
Adapter complete with three-jaw chuck, opening 1-16mm, for drill Art. 3078 Ge.
O3078GE
Each 34,60
vuoto
PILLARDRILLSWITHMAGNETICSUPPORT
