497
Prices in EURO - VAT not included
7
497
AIR RATCHES
1716GE
Prod. Pneutec - Art. UT 8018
Professional type.
Very high performance model for continuous screwing operation. With lever change for clockwise
and counter clockwise one-hand operation. Aluminium housing.
Drive for bushes
inch 1/2
Max torque
Nm 130
For bolts up to
M.
16
Air consumption
l/sec
6
No-load speed
rev/min 170
Length
mm 370
Noise level
dB 94,7
Vibrations
m/s²
8,8
Air drive
inch 1/4
Weight
Kg
1,6
1716GE
Each 450,00
Operating pressure: Atm 6,3.
vuoto
AIRRATCHES
AIR DRILLS
1717GE
Prod. Pneutec - Art. UT 8831
Pistol grip handle.
Made of composite material and bi-component handle. Air discharge in the handle bottom end.
Standard type with left-right rotation for light-duty works, three-jaw chuck
shank 3/8"x 24 threads (Art. 1495 G 10).
Chuck opening and bores steel
mm 10
Air consumption
l/sec
2,6
No-load speed
rev/min 2200
Length
mm 160
Noise level
dB
84
Vibrations
m/s²
< 2,5
Air drive
inch
1/4
Weight
Kg
1
1717GE
Each 206,00
Operating pressure Atm 6,3.
A drill with the same performance levels but with a quick opening spindle.
vuoto
AIRDRILLS
1717GL
Prod. Pneutec - Art. UT 8844 RE
Pistol grip handle.
Light alloy manufacture, particularly handy. Air discharge in the handle bottom end, rubber-
coated.
Type with RIGHT/LEFT rotation, quick closing chuck, shank 3/8"x 24 threads (Art. 1513 G 10).
Chuck opening and bores steel
mm 10
Air consumption
l/sec
7
No-load speed
rev/min 2000
Length
mm 160
Noise level
dB
96
Vibrations
m/s²
< 2,5
Air drive
inch
1/4
Weight
Kg
1,8
1717GL
Each 243,00
Operating pressure: Atm 6,3.
vuoto
AIRDRILLS
1718GB
Prod. Pneutec - Art. UT 8855 RE
Product description as Art. 1717GL
Professional type with RIGHT/LEFT rotation, high-performance for heavy-duty works, quick
closing chuck, shank 1/2"x 20 threads (Art. 1513 G 13A). With additional handle.
Chuck opening and bores steel
mm 13
Air consumption
l/sec
7
No-load speed
rev/min 450
Length
mm 184
Noise level
dB
84
Vibrations
m/s²
< 2,5
Air drive
inch
1/4
Weight
Kg
1,4
1718GB
Each 281,00
Operating pressure: Atm 6,3.
vuoto
AIRDRILLS
