499 / 1410
499
Prices in EURO - VAT not included
7
499
AIR CUT-OFF MACHINES
AIR CUT-OFF MACHINES
1718GR
Prod. Pneutec - Art. UT 5760 B
Grinder model, to cut iron, metal and alloy steel. Continuous adjustment of the speed of rotation.
High manoeuvrability and comfort, body made of composite material, very sturdy. Air outlet on the
back.
Transparent start lever for the safety and protection of the grinder. Comes with 1 cutting disc.
For cutting wheels
mm 76x2x10
Working torque
Nm 0,3
Air consumption
l/sec
3
No-load speed
rev/min 20000
Length
mm 175
Noise level
dB
84
Vibrations
m/s²
<2,5
Air drive
inch
1/4
Weight
Kg
0,7
1718GR
Each 168,00
Operating pressure Atm 6,3.
vuoto
Spare cutting discs Ø 76 mm, 2 mm thick, 10 mm hole.
For Art. 1718 GR.
O1718GRA
Each 18,70
AIRCUT-OFFMACHINES
AIR ROTARY DIE GRINDERS
1718GT
Prod. Pneutec - Art. UT 8742 R
Stylus type.
Particularly suitable for use with tyre tools.
Aluminium body, thermally insulated for heavy-duty works. Big and spaced unloading device.
Collet chuck. 6 bar power: KW 0.4. Starter with safety lever.
For tools with shaft Ø mm 6
Air consumption
l/sec
8
No-load speed
rev/min 4000
Length
mm 190
Noise level
dB
89
Vibrations
m/s²
< 2,5
Air drive
inch
1/4
Weight
Kg
1
1718GT
Each 311,00
Operating pressure: Atm 6,3
AIRROTARYDIEGRINDERS
1718GZ
Prod. Pneutec - Art. UT 5710
Stylus model, low air consumption.
High frequency rotation with little fall in the number of revolutions, even under pressure. High
manoeuvrability and comfort, body made from extremely sturdy composite material.
Air outlet on the back.
Collet chuck. Power at 6 bar: KW 0.2. Starter with safety lever.
For tools with shaft Ø mm 6
Air consumption
l/sec
2
No-load speed
rev/min 20000
Length
mm 170
Noise level
dB
79
Vibrations
m/s²
< 2,5
Air drive
inch
1/4
Weight
Kg
0,6
1718GZ
Each 149,00
Operating pressure Atm 6,3.
For spare pliers see Art. O1719 G.
AIRROTARYDIEGRINDERS
1719G
Prod. Pneutec - Art. UT 5720
Stylus type.
High-frequency rotation with linited rpm reduction, even under strong pressure. Particularly handy
for use of light alloys.
Air discharge in the rear part.
Collet chuck. 6 bar power: KW 0.2. Starter with safety lever.
For tools with shaft Ø mm 6
Air consumption
l/sec
8,5
No-load speed
rev/min 22000
Length
mm 176
Noise level
dB 86,8
Vibrations
m/s²
< 2,5
Air drive
inch
1/4
Weight
Kg
0,6
1719G
Each 149,00
Operating pressure Atm 6,3.
vuoto
Spare collets Ø 6mm, for Art. 1718 GZ and 1719 G.
O1719G
Each 36,80
AIRROTARYDIEGRINDERS
