492 / 1410
492
Prices in EURO - VAT not included
7
492
AIR IMPACT WRENCHES
1714GL
Prod. Pneutec - Art. UT 81452 RE
Product description as Art. 1714GE
Prolonged pin, 50mm, particularly suited to truck coupled wheels.
Drive for bushes
inch 1/2 long
Max working torque
Nm 495/600
For bolts up to
M.
22
Air consumption
l/sec
6,9
No-load speed
rev/min 7500
Length
mm 230
Noise level
dB 90,3
Vibrations
m/s²
2,6
Air drive
inch
1/4
Weight
Kg
2,7
1714GL
Each 300,00
Operating pressure: Atm 6,3.
vuoto
AIR IMPACTWRENCHES
1714GM
Prod. Pneutec - Art. UT 8137
Pistol model, professional.
High performance with a percussion for each rotation. With three levels of screwing power. Switch
for left and right rotation, while a deadlock prevents any accidental rotation, can be used WITH
ONE HAND ONLY. Easy accessible mechanical parts. High comfort thanks to the handle covered
in dual-component material. Air can be extracted from the handle, downward motion.
Drive for bushes
inch
1/2
Max working torque
Nm 400/600
For bolts up to
M.
24
Air consumption
l/sec
2,9
No-load speed
rev/min 6500
Length
mm 200
Noise level
dB
85
Vibrations
m/s²
6,7
Air drive
inch
1/4
Weight
Kg
2,1
1714GM
Each 225,00
Operating pressure Atm 6,3.
vuoto
AIR IMPACTWRENCHES
1714GPA
Prod. Pneutec - Art. UT 8157
Professional, pistol-grip type, double hammer.
Very high torque, particularly low noise level and long-lasting operation. With three screwing force
settings. Switch for right and left rotation. Extremely high comfort thanks to the handle coated with
bi-component material. Air exhaust through the handle, downwards.
Drive for bushes
inch
1/2
Max working torque
Nm 700/950
For bolts up to
M.
24
Air consumption
l/sec
2,5
No-load speed
rev/min 6000
Length
mm 192
Noise level
dB 85,0
Vibrations
m/s²
6,7
Air drive
inch
1/4
Weight
Kg
2
1714GPA
Each 375,00
Operating pressure: Atm 6,3.
vuoto
AIR IMPACTWRENCHES
1714GR
Prod. Pneutec - Art. UT 8150
Professional, pistol-grip type, double hammer.
Very high torque, very low air consumption and long-lasting operation. With three screwing force
settings and rapid acceleration. Switch for right and left rotation. Extremely comfortable and easy
to handle, thanks to the very sturdy, light-weight body made from composite material. Air exhaust
through the handle, downwards.
Drive for bushes
inch
1/2
Max working torque
Nm 830/950
For bolts up to
M.
24
Air consumption
l/sec
1,9
No-load speed
rev/min 7000
Length
mm 190
Noise level
dB 83,0
Vibrations
m/s²
< 2,5
Air drive
inch
1/4
Weight
Kg
1,8
1714GR
Each 450,00
Operating pressure: Atm 6,3.
vuoto
AIR IMPACTWRENCHES
