CABLE STRIPPER FOR INDUSTRIAL USE
2
28
Prices in EURO - VAT not included
202GC
For removing thick insulating sheaths from conductors through circular and longitudinal cutting.
Body in fiberglass reinforced polyamide.
Blade and knurled sliding wheel made of steel. Blade depth adjustment through
special screw. Reversible blade to be used in both directions and sides.
Capacity by Ø
mm 25
Blade max depth
mm 5
Overall length as closed mm 150
202GC
Each 304,00
vuoto
Spare blades for Art. 202 GC.
O202GC
Each 98,90
vuoto
CABLESTRIPPERFOR INDUSTRIALUSE
202GCE
Orig. Gedore - Art. 137 ISOCUT
For stripping ground or high voltage cables with 1 or more insulating layers up to a diameter of 42
mm. Allows the possibility to perform circular and longitudinal cuts by rotating the blade, and by
pressing the button on the head of the pliers. Adjustable screw depth cuttings. Immediate
clamping and release, covered by a lever. Drop forged jaws and a hardened body made from
sturdy sheet steel.
Capacity for Ø up to
mm 42
Cutting max depth
mm 14
Weight
Kg 0,840
202GCE
Each 195,00
Product running out of stock
vuoto
CABLESTRIPPERFOR INDUSTRIALUSE
CRIMPING PLIERS FOR COAXIAL CONNECTORS
202GCP
Orig. Gedore - Art. 8140
Professional modular ratchet crimping tool to crimp most of mechanical, electric and electronic
connectors.
The pliers can be equipped with different modular bits.
Use pros: crimping reliability and precision thanks to parallel stroke mechanism. User-friendly
due to perfect visibility during crimping process and rapid release function for bit replacement with
no tool required. Tool lightness assures max. comfort. Easy- to-use thanks to the interchangeable
modular bits clearly marked according to their use. Versatility and low price for a pliers to be used
with different kinds of connectors (power, coaxial, phone and optical fibres connectors).
PLIERS WITHOUT BITS
Overall length
mm 234
202GCP
Each 112,00
vuoto
CRIMPINGPLIERSFORCOAXIALCONNECTORS
202GCS 1
Orig. Gedore - Art. 8140-01
MODULAR BITS FOR PLIERS ART. 202 GCP
Connector type
Pre-insulated terminals
For cables by
mm²
0,1-0,4 + 4-6 (AWG 26-22 + 12-10)
202GCS 1
Each
61,70
vuoto
CRIMPINGPLIERSFORCOAXIALCONNECTORS
202GCS 2
Orig. Gedore - Art. 8140-02
MODULAR BITS FOR PLIERS ART. 202 GCP
Connector type
Pre-insulated terminals
For cables by
mm² 0,5-1,5 + 1,5-2,5 (AWG 22-16 + 16-14)
202GCS 2
Each
61,70
vuoto
CRIMPINGPLIERSFORCOAXIALCONNECTORS
202GCS 3
Orig. Gedore - Art. 8140-03
MODULAR BITS FOR PLIERS ART. 202 GCP
Connector type
Non-insulated terminals
For cables by
mm²
4-6-10
202GCS 3
Each
61,70
vuoto
CRIMPINGPLIERSFORCOAXIALCONNECTORS
