33 / 1410
33
CRIMPING PLIERS FOR SCOTCHLOK CONNECTORS
2
33
Prices in EURO - VAT not included
CRIMPING PLIERS FOR SCOTCHLOK CONNECTORS
203G
Prod. SCU
In forged steel. Polished head, plastic-coated handles.
Nose parallel clamping, induction hardened cutter.
With spring.
Suitable for clamping SCOTCHLOK connectors.
Overall length
mm 150
203G
Each 32,90
vuoto
CRIMPINGPLIERSFORSCOTCHLOKCONNECTORS
CRIMPING PLIERS FOR PRE-INSULATED TERMINALS
204G
Prod. SCU
In alloy steel, hardened operating parts. With cable cutter. PVC-coated handles.
Cable lugs for cables by mm²
1.5 to 6
Bolt cutters by
M 2.6 to 5
Stripper for cables by
mm²
0.75 to 6
Overall length
mm 205
204G
Each 6,20
vuoto
CRIMPINGPLIERSFORPRE-INSULATEDTERMINALS
205G
Orig. Marvel
In special steel. Combined with threaded screw cutters, wire strippers and cable cutters with
lapped cutting edges additionally induction hardened. Plastic-coated handles. Thickness 3,2mm.
Joint pin amply dimensioned and hardened.
Cable lugs for cables by mm²
1.5 to 6
Bolt cutters by
M 2.6 to M 5
Stripper for cables by
mm²
0.75 to 6
Wire cutter by
mm²
0.5 to 6
Overall length
mm²
220
205G
Each
20,30
CRIMPINGPLIERSFORPRE-INSULATEDTERMINALS
PLIERS FOR INSULATED WIRE TERMINALS
205G 8
Prod. SCU
Professional heavy type, mod. ZENITH C60 made from special steel. Working parts are hardened
and finely tuned.
Combined with threaded cutters, wire strippers and cutters with edges which have been further
hardened through induction. Handle with plastic coating. 4 mm thick. Generously sized hinge pin,
tempered, and finely tuned.
Cable lugs for cables by mm²
1,5 to 8
Bolt cutters by
M 2,5 to M 5
Wire cutter by inches
W 3/32 to W 3/16
Stripper for cables by
mm²
2 to 8
Wire cutter by
mm²
0,5 to 8
Overall length
mm²
215
205G 8
Each
46,80
PLIERSFOR INSULATEDWIRETERMINALS
CRIMPING PLIERS FOR PRE-INSULATED TERMINALS
205GB
Orig. Gedore - Art. 8155
Professional with automatic opening after locking. In special steel, operating parts hardened and
ground. Insulated handles, in synthetic material. With release device in case faulty wiring.
Cable lugs for cables by mm² 0,5 to 6
Overall length
mm 220
205GB
Each 136,00
vuoto
CRIMPINGPLIERSFORPRE-INSULATEDTERMINALS
205GC
Prod. SCU
Combined opening once the terminal is locked. In special steel, ground and hardened operating
parts. Synthetic material coated handles.
Equipped with release device in case of faulty cabling.
Cable lugs for cables by mm²
1.5 to 6
Overall length
mm 230
205GC
Each 59,80
Not available spare inserts.
CRIMPINGPLIERSFORPRE-INSULATEDTERMINALS
205GD
Orig. Marvel
Double-lever pliers with fine tooth movement for terminal clamping.
Automatic opening once the terminal is locked.
CHROME-MOLYBDENUM steel head, fully hardened, lapped cutting edges. With soft rubber
handles.
Cable lugs for cables by mm²
1.5 to 6
Overall length
mm 240
205GD
Each 156,00
CRIMPINGPLIERSFORPRE-INSULATEDTERMINALS
