SPRING CABLE STRIPPERS
2
27
Prices in EURO - VAT not included
199GTA
Suitable for circular and longitudinal cutting to remove insulating sheaths from conductors.
Body made of synthetic material reinforced with fiberglass.
Blade in hardened steel. With wire cutter for cutting wires up to mm
2
2.
To strip wires with cross sections from mm
2
0.5 to 6. With spring and latch.
Length 150 mm.
Capacity for Ø
mm 8 to 13
199GTA
Each 32,10
vuoto
SPRINGCABLESTRIPPERS
199GV
Product description as Art. 199GTA
Steel blade with variable depth. Two positions adjustable cable seal arc.
Rear blade to remove the insulation of the conductor cross sections from mm
2
0.5 to 6.
Length 155 mm.
Capacity for Ø
mm 4 to 28
199GV
Each 48,90
vuoto
Spare blades for Art.199 GV.
O199GV
Each 6,98
vuoto
SPRINGCABLESTRIPPERS
200G
For removing insulating cable conductor sleeves with circular
and longitudinal incision. Body coated steel, steel blade.
Adjustable blade depth, bow cable sealing chuck.
Side button for the 90 ° blade orientation. Length 135 mm.
Capacity for Ø
mm 4.5 to 28.5
Blade max depth
mm 3
Weight
grams
120
200G
Each 41,20
For spare blades see Art. O200 GA.
vuoto
SPRINGCABLESTRIPPERS
200GA
Product description as Art. 200G
For removing insulating sheaths from conductors through circular and longitudinal cutting. Body
made of coated steel, steel blade.
Blade depth adjustment, self-locking cable holding device.
Capacity for Ø
mm 4.5 to 28.5
Blade max depth
mm 3
Weight
grams
120
200GA
Each 46,70
vuoto
Spare blades for Art.200 GA.
O200GA
Each 8,28
vuoto
SPRINGCABLESTRIPPERS
CABLE STRIPPER FOR INDUSTRIAL USE
201G
Prod. SCU
For removing insulating sheaths from conductors, even coaxial, through circular and longitudinal
cutting. Body made of coated steel, steel blade. Blade depth adjustment, cable holding device
adjustable through a locking knurled roller. Side button for blade orientation to 90°. Length
160mm.
Capacity for Ø
mm 8 to 33
Blade max depth
mm 4,5
Weight
grams 165
201G
Each 117,00
vuoto
Spare blades for Art.201 G.
O201GP
Each 14,10
vuoto
CABLESTRIPPERFOR INDUSTRIALUSE
202GB
For removing thick insulating sheaths from large conductors through circular, longitudinal and
diagonal cutting. Body in high-resistance steel and die-cast ALUMINIUM alloy. SUPER-RAPID
steel blade. With micrometric screw for blade depth adjustment
. Knife step-rotation by 45° - 90° - 180°. Extractable handle for adjustment and clamping in the
desired diameters. With rollers for easy sliding on the sheath, rapid closing for cable clamping.
The 202 GB type is equipped with 2 inserts:
length mm 95 for cables ext. Ø from 30 to 52 mm
length mm 127 for cables ext. Ø from 20 to 44 mm.
Capacity for Ø
mm 20 to 52
Blade max depth
mm 5
Weight
grams 640
202GB
Each 566,00
vuoto
Spare blades for Art.202 GB.
O202G
Each 16,30
vuoto
CABLESTRIPPERFOR INDUSTRIALUSE
