HYDRAULIC PIPE BENDERS
2
168
Prices in EURO - VAT not included
784W
ADDITIONAL DIES ONLY FOR ART. 784 R
For steel, semicrude copper, MEPLA, GEBERIT and similar with thickness up to 1,5mm (from
24mm to 35mm only for coated pipes MEPLA, GEBERIT and similar).
For pipes Ø
mm
18
19
22
24
25
26
30
Bending radius
mm 70
70
110
110
110
110
110
784W
Each 73,30 85,50 97,70 110,00 123,00 135,00 135,00
For pipes Ø
mm
32
35
40
Bending radius
mm 110
110
120
784W
Each 97,70 135,00 97,70
vuoto
COPPIE BRACCETTI SUPPLEMENTARI
Necessary to install 784 W dies 22 to 35mm on 784 R pipe bender pump. To bend coated pipes
fron 22mm to 40mm and to bend pipes MEPLA, GEBERIT, STARGAS, etc.
O784W
Per pair 147,00
vuoto
HYDRAULICPIPEBENDERS
784Z
Device used for bending and straightening pipes. For right or left bends.
For cold bending of empty gas pipes up to 90°. Mini model.
With no. 4 dies for pipes ranging from 3/8-1/2-3/4-1 inches (mm 17-21-27-33).
Complete in case.
784Z
Each 919,00
vuoto
HYDRAULICPIPEBENDERS
785A
785B
785C
785D
785E
Device used for bending and straightening pipes. For right or left bends.
For cold bending of empty gas pipes up to 90°.
Very powerful pump.
With 5 dies for pipes ranging from 3/8-1/2-3/4-1- 1.1/4 inches (17-21-27-33-42mm).
Complete boxed set.
785A
Each 1.130,00
vuoto
Product description as Art. 785A
With no. 6 dies for pipes ranging from 3/8-1/2-3/4-1-1.1/4- 1.1/2 inches (mm 17-21-27-33-42-48).
In wood box.
785B
Each 1.200,00
vuoto
Product description as Art. 785A
With no. 7 dies for pipes ranging from 3/8-1/2-3/4-1-1.1/4-1.1/2-2 (mm 17-21-27-33-42-48-60).
In wood box.
785C
Each 1.770,00
vuoto
Product description as Art. 785A
With no. 9 dies for pipes ranging from 3/8-1/2-3/4-1-1.1/4-1.1/2-2-2.1/2-3 inches (mm 17-21-27-33-
42-48-60-75-88).
In wood box.
785D
Each 2.820,00
vuoto
Product description as Art. 785A
With no. 11 dies for pipes ranging from 3/8-1/2-3/4-1-1.1/4-1.1/2-2-2.1/2-3-3.1/2-4 inches (mm 17-
21-27-33-42-48-60-75-88-100-113).
In wood box.
785E
Each 4.300,00
vuoto
HYDRAULICPIPEBENDERS
785M
DIES FOR HYDRAULIC TUBING BENDERS ART. 784 Z – 785 A-B-C-D-E.
For pipes Ø
inch
3/8
1/2
3/4
1
1.1/4 1.1/2
2
2.1/2
Bending radius
mm 45
55
70
95
135 155 200 320
785M
Each 51,90 58,80 76,10 101,00 132,00 173,00 277,00 484,00
For pipes Ø
inch
3
3.1/2
4
Bending radius
mm 350 540 600
785M
Each 623,00 267,00 329,00
For pipes Ø
mm
10
12
14
16
18
20
22
24
Bending radius
mm 35
35
40
45
45
55
55
55
785M
Each 55,30 58,80 62,20 65,70 69,20 69,20 93,30 101,00
For pipes Ø
mm
26
28
30
32
35
38
40
Bending radius
mm 70
70
70
90
95
95
130
785M
Each 108,00 121,00 128,00 135,00 149,00 166,00 177,00
vuoto
