167 / 1410
167
UNIVERSAL TUBE BENDERS
2
167
Prices in EURO - VAT not included
UNIVERSAL TUBE BENDERS
784G
Prod. SCU
Hand device used for cold/hot bending of empty thin steel and copper pipes. Conform to
European specifications DIN EN 1057 . For perfect bending from 0° to 180°. Each diameter to
bend needs suitable die and guide supplied in couples. The bender handle may be lengthened by
a pipe Ø 1.1/4". The device is supplied together with a base to be bolted to the working desk by
means of a tubing bender with ridged roller and cylindrical pressure roller.
Dies and guides excluded and supplied aside. See Art. 784 L-M-N.
Without dies, guides and lever, in box.
784G
Each 646,00
For perfect bending, pipe minimum thicknesses as indicated on dies must be respected.
Product only available while stocks last.
vuoto
UNIVERSALTUBEBENDERS
784L
784M
784N
DIES AND GUIDES FOR TUBING BENDERS 784 G.
FOR BENDING THIN STEEL PIPES.
The couple is made of 1 die + 1 guide.
For pipes Ø ext
mm
10
19
25
28
32
Min thickness
mm 1
1,25 1,50 1,50 1,50
Bending radius
mm 40
68
105
126
153
784L
Per pair 258,00 379,00 568,00 639,00 819,00
Product running out of stock
vuoto
FOR BENDING COPPER PIPES.
The couple is made of 1 die + 1 guide.
For pipes Ø ext
mm
6
8
10
12
15
22
28
35
Min thickness
mm 1
1
1
1
1
1,1 1,2 1,3
Bending radius
mm 40
40
40
50
68
81 126 175
784M
Per pair 258,00 258,00 258,00 274,00 379,00 434,00 639,00 1.610,00
The die for Ø mm. 35 is supplied with additional tool.
Product running out of stock
vuoto
FOR BENDING PLASTIFIED WICO PIPES.
The couple is made of 1 die + 1 guide.
Pipe ext Ø without covering mm
6
8
10
12
15
22
Pipe ext Ø with covering
mm 10
12
14
16
20
26
Min thickness
mm 1
1
1
1
1
1,1
Bending radius
mm 40
50
50
68
68
105
784N
Per pair 258,00 274,00 274,00 379,00 379,00 568,00
Product running out of stock
vuoto
Adjustable spacer.
O784P
Each 78,30
Product running out of stock
Adjustable 180° revolving base.
O784R
Each 238,00
Product running out of stock
UNIVERSALTUBEBENDERS
HYDRAULIC PIPE BENDERS
784P
Prod. SCU
Body and dies in light alloy.
Rotating fork for all-position use.
Hand-operated hydraulic pump. For aluminium, annealed copper, annealed brass, annealed
steel, CHIBRO and MANNESMANN, stainless steel up to Ø 16x1,5mm.
GAS pipes Ø 1/2, MEPLA, GEBERIT and similar pipes up to Ø 26mm.
Light type with no. 9 dies Ø mm. 10-12-14-15-16-18-20-22-26 (mm. 26 only for MEPLA,
GEBERIT or similar pipes).
In plastic case.
784P
Each 489,00
vuoto
HYDRAULICPIPEBENDERS
784R
Body and dies in light alloy.
Rotating fork for all-position use.
Hand-operated hydraulic pump. For aluminium, annealed copper, annealed brass, annealed
steel, CHIBRO,MANNESMANN and stainless steel up to Ø 22x1,5mm.
GAS pipes Ø 1/2, MEPLA, GEBERIT and similar pipes up to Ø 26mm.
Professional type with very powerful pump. With no. 11 dies Ø mm. 10-12-14-15-16-18-20-22-24-
26-1/2 gas. (mm. 26 only for MEPLA, GEBERIT and similar).
In plastic case.
784R
Each 684,00
vuoto
MATRICI DI RICAMBIO PER ART. 784 P - R
For pipes Ø
mm
10 12 14 15 16 18 20 22 24 26
Bending radius
mm 25 35 40 48 60 60 60 70 70 70
O784U
Each 36,70 36,70 48,90 48,84 61,10 61,10 61,10 73,30 73,30 73,30
vuoto
