1125 / 1410
1125
Prices in EURO - VAT not included
1125
CARBIDE TIPPED TWIST DRILLS, RIGHT-HAND ROTATION
13
CARBIDE TIPPED TWIST DRILLS, RIGHT-HAND ROTATION
8330G
HARTMETALL
Prod. SCU - Art. 89303
DIN 8038. HSS body, SOLID CARBIDE cutting edges.
Cutting angle 85°.EXTRA-SHORT pattern.
For static machines. For drilling high-resistance synthetic materials.
Cylindrical shank.
Ø
mm
4
4,5
5
5,5
6
6,5
7
Overall length
mm 56
63
63
71
71
71
80
Helix length
mm 25
28
28
30
30
32
40
8330G
Each 26,90 26,60 33,20 39,70 34,50 29,40 25,20
Ø
mm
7,5
9
9,5
10
15
Overall length
mm 80
90
90
100
125
Helix length
mm 40
50
50
56
71
8330G
Each 26,60 36,20 44,30 47,20 95,30
Product running out of stock
vuoto
CARBIDETIPPEDTWISTDRILLS,RIGHT-HANDROTATION
8331G
HARTMETALL
Prod. SCU - Art. 89301
DIN 8037. HSS body, SOLID CARBIDE cutting edges.
Cutting angle 118°.EXTRA-SHORT pattern.
For static machines. For drilling high-resistance cast iron and steel, pure molybdenum and soft
metal alloys.
Cylindrical shank.
Ø
mm
3
3,1 3,2 3,3 3,5 3,6*
3,7 3,8*
3,9*
4
4,2 4,4*
4,5 4,7*
4,8
Overall length
mm 50
56
56
56
56
56
56
56
56
56
63
63
63
63
63
Helix length
mm 20
25
25
25
25
25
25
25
25
25
28
28
28
28
28
8331G
Each 22,10 36,50 31,30 31,30 22,80 20,30 31,90 27,40 35,20 19,60 24,10 29,30 20,30 25,10 24,80
Ø
mm
4,9*
5
5,1*
5,2 5,3*
5,4*
5,5 5,6*
5,7*
5,9*
6
6,1*
6,2*
6,3 6,4*
Overall length
mm 63
63
71
71
71
71
71
71
71
71
71
71
71
71
71
Helix length
mm 28
28
30
30
30
30
30
30
30
30
30
30
30
30
30
8331G
Each 31,90 20,10 31,90 31,90 35,20 36,50 22,80 22,50 21,60 20,50 21,50 32,80 36,50 35,20 30,60
Ø
mm
6,5 6,6*
6,7 6,8 6,9*
7
7,2 7,3*
7,4 7,5 7,6*
7,7 7,8*
7,9*
8
Overall length
mm 71
80
80
80
80
80
80
80
80
80
80
80
80
80
80
Helix length
mm 32
40
40
40
40
40
40
40
40
40
40
40
40
40
40
8331G
Each 22,70 23,90 32,60 30,60 31,10 23,80 38,40 30,30 31,90 28,10 27,20 31,90 38,40 30,30 25,10
Ø
mm
8,2 8,5
9
9,5
10 10,5 11 11,5 12 12,5 13 13,5*
14 14,5 16
Overall length
mm 90
90
90
90 100 100 100 112 112 112 112 125 125 125 140
Helix length
mm 50
50
50
50
56
56
56
63
63
63
63
71
71
71
80
8331G
Each 41,70 30,60 28,10 37,80 34,50 45,60 38,40 61,80 40,40 61,20 54,70 87,20 63,80 103,00 87,20
Ø
mm
16,5 18 18,5 19,5 20
Overall length
mm 140 160 160 160 160
Helix length
mm 80
90
90
90
90
8331G
Each 123,00 131,00 157,00 209,00 180,00
* Sizes running out of stock
CARBIDETIPPEDTWISTDRILLS,RIGHT-HANDROTATION
SOLID CARBIDE TWIST DRILLS, K 10/20, RIGHT-HAND ROTATION
8334G
HARTMETALL
Orig. Hartner - Art. 89246
DIN 6540. Type NR, two cutting edges. Cutting angle 130°.
EXTRA-SHORT pattern. For static and CNC machines.
For high-resistance synthetic materials.
Cylindrical shank.
Ø
mm
0,5 0,7*
0,8 0,9*
1 1,1*
1,2 1,3*
1,4*
Overall length
mm 30 30 30 30 30 30 30 30 30
Helix length
mm 5,5 6,5 8,5 9,5 11 11 13 13 13
8334G
Each 11,80 7,98 11,90 12,50 9,76 7,58 11,90 7,58 10,80
Ø
mm
1,6*
1,7 1,8*
1,9*
2
3
4 5,5*
Overall length
mm 40 40 40 40 40 45 50 50
Helix length
mm 17,5 17,5 17,5 17,5 17,5 20 22 25
8334G
Each 8,28 11,80 8,28 8,28 10,20 16,30 28,70 34,40
* Sizes running out of stock
vuoto
SOLIDCARBIDETWISTDRILLS,K10/20,RIGHT-HANDROTATION
