DRILLS FOR STAINLESS STEEL AND ALLOYS, RIGHT-HAND ROTATION
13
Ø
mm
5,8 5,9
6
6,1 6,2*
6,3 6,4*
6,5 6,6 6,7 6,8 6,9
7
7,1 7,2*
Overall length
mm 66
66
66
70
70
70
70
70
70
70
74
74
74
74
74
Helix length
mm 28
28
28
31
31
31
31
31
31
31
34
34
34
34
34
8315G
Each 32,20 33,10 16,70 35,10 22,30 38,90 24,50 19,20 41,30 38,90 38,90 36,10 25,10 45,60 28,40
Ø
mm
7,4 7,5 7,6 7,7*
7,8 7,9
8
8,1 8,2*
8,3*
8,4*
8,5 8,7 8,8*
9
Overall length
mm 74
74
79
79
79
79
79
79
79
79
79
79
84
84
84
Helix length
mm 34
34
37
37
37
37
37
37
37
37
37
37
40
40
40
8315G
Each 47,50 25,90 44,60 32,80 53,70 72,90 22,60 48,10 48,90 40,10 41,10 28,80 70,10 45,10 35,10
Ø
mm
9,2 9,3*
9,4*
9,5 9,6*
9,8*
10 10,2 10,5 10,6* 11,5
Overall length
mm 84
84
84
84
89
89
89
89
89
89
95
Helix length
mm 40
40
40
40
43
43
43
43
43
43
47
8315G
Each 67,10 52,20 68,30 37,90 52,20 53,90 36,10 69,10 68,10 83,30 91,10
Up to Ø 7.5mm in 10pcs packing units. - * Sizes running out of stock
DRILLSFORSTAINLESSSTEELANDALLOYS,RIGHT-HANDROTATION
STUB DRILLS, RIGHT HAND CUTTING
8325G
HSS
TIN
Orig. Hartner - Art. 84400
DIN 1897. Type N. HSS+TIN. Cutting angle 118°.
EXTRA-SHORT pattern.
Sharpening according to DIN 1414, Form N.
For alloy steel up to R 900 N/sqmm, cast iron, spheroidal cast iron, aluminium and short-chip
aluminium alloys, bronze and electrolitic copper.
Cylindrical shank. TIN treatment.
Ø
mm
2
2,5
3
3,5
4
4,5
5
5,5
6
6,5
7
7,5
8
8,5
9
9,5
Overall length
mm 38 43 46 52 55 58 62 66 66 70 74 74 79 79 84 84
Helix length
mm 12 14 16 20 22 24 26 28 28 31 34 34 37 37 40 40
8325G
Each 9,66 10,30 10,30 10,70 10,70 11,20 11,60 13,10 13,10 22,60 24,20 26,70 25,20 29,30 28,30 36,10
Ø
mm
10 10,5 11 11,5 12 13 13,5 14 14,5 15 16 17 17,5 18 20
Overall length
mm 89 89 95 95 102 102 107 107 111 111 115 119 123 123 131
Helix length
mm 43 43 47 47 51 51 54 54 56 56 58 60 62 62 66
8325G
Each 31,40 46,30 43,70 50,40 51,40 53,40 68,80 59,60 64,70 66,80 73,10 84,30 88,40 83,20 97,60
Up to Ø 7.5mm in 10pcs packing units.
STUBDRILLS,RIGHTHANDCUTTING
8326G
HSS-E
TIN
Orig. Hartner - Art. 84805
Spiral flute length according to DIN 1897. Type FU 500. COBALT HSS-E+TIN. Cutting angle 118°.
EXTRA-SHORT pattern.
Particular 4 facet grinding and special web thinning for low turning moments, higher drilling
parameters and good finishing of the hole surface.
For alloy and unalloyed steel up to R 850 N/sqmm, steel for hot/cold working, bearing steel,
stainless steel, non-ferrous metals, cast iron and plastic materials.
Cylindrical shank according to DIN 1835A. TIN treatment.
Ø
mm
2
2,5
3
3,3
4
4,2 4,5*
5
5,5
6
6,5 6,8
7
7,5
8
Overall length
mm 44
46
48
50
54
66
68
70
72
72
75
78
78
78
81
Helix length
mm 12
14
16
18
22
22
24
26
28
28
31
34
34
34
37
Drive Ø
mm 3
3
3
4
4
6
6
6
6
6
8
8
8
8
8
Drive length
mm 28
28
28
28
28
36
36
36
36
36
36
36
36
36
36
8326G
Each 15,60 17,50 17,50 20,70 23,10 25,50 25,50 33,90 33,90 36,90 43,10 44,50 44,50 47,50 48,20
Ø
mm
8,5
9*
9,5
10 10,2 10,5 11*
12
14 15*
17 18*
19*
20*
Overall length
mm 87
91
91
93 100 100 104 108 114 116 126 128 130 132
Helix length
mm 37
40
40
43
43
43
47
51
54
56
60
62
64
66
Drive Ø
mm 10
10
10
10
12
12
12
12
16
16
20
20
20
20
Drive length
mm 40
40
40
40
45
45
45
45
48
48
50
50
50
50
8326G
Each 53,50 56,50 61,80 65,60 79,90 79,90 87,40 103,00 190,00 219,00 249,00 270,00 308,00 317,00
* Sizes running out of stock
STUBDRILLS,RIGHTHANDCUTTING
8328G
HSS-E
FIRE
Orig. Hartner - Art. 84511
DIN 1897. Type FN 500. COBALT HSS-E + FIRE. Cutting angle 130°.EXTRA-SHORT pattern.
High-performance drills, excellent heat resistance, wide slots. Produced by using the powder-
sintering technique (PM), such drills combine the advantages of conventional Cobalt HSS-E and
solid carbid drills, resulting cheaper and less subject to breakage. FIRE-coated surface, for high-
speed working, dry working, or when using nebulized lubrication-cooler.
For high-percentage alloy steel, quenched and tempered steel and case hardening steel, cast
iron, brass and bronze.
Cylindrical shank. FIRE treatment.
Ø
mm
2
2,5
3
3,3
3,5
4
4,2
4,5
5
5,5
6
6,5
6,8
Overall length
mm 38
43
46
49
52
55
55
58
62
66
66
70
74
Helix length
mm 12
14
16
18
20
22
22
24
26
28
28
31
34
8328G
Each 18,10 19,80 23,70 23,10 21,70 21,10 21,30 20,40 23,10 25,60 26,10 28,10 53,50
Ø
mm
7
7,5
8
8,5
9
9,5
10
10,2 10,5
11
11,5
12
13
Overall length
mm 74
74
79
79
84
84
89
89
89
95
95
102
102
Helix length
mm 34
34
37
37
40
40
43
43
43
47
47
51
51
8328G
Each 43,10 44,50 46,70 49,10 55,10 70,10 62,50 91,90 88,90 94,90 99,40 107,00 116,00
STUBDRILLS,RIGHTHANDCUTTING
