UNIVERSAL STEEL BAR CLAMPS

12

5245GS

Product description as Art. 5245GR

Reinforced model. Throat: 175mm. Bar cross section 40x20mm. Reachable pressure with

150mm opening: approx. 22000 N (2200 kg) equivalent to 80Nm torque value.

Useful opening

mm

300

400

500

600

800

1000 1250

Weight

Kg 5,50

6,10

6,60

7,20

8,30

9,40 10,80

5245GS

Each 116,00 127,00 139,00 150,00 162,00 193,00 223,00

Useful opening

mm

1500

Weight

Kg 12,10

5245GS

Each 250,00

vuoto

UNIVERSALSTEELBARCLAMPS

UNIVERSAL STEEL BAR CLAMPS, QUICK LOCKING

5245GSE

Orig. Kanca

In forged and hardened steel, profiled bar. For rapid locking.

Rack clamping with toothed bar.

Highest strength even in case of vibrations.

Useful opening

mm

160

200

250

300

400

500

600

Depth

mm 80

100

120

140

120

120

120

Rod section

mm 16x7,5 19,5x9,5 22x10,5 25x12 25x12 25x12 25x12

Tightening force

N 2300 3500 4500 5000 5500 5500 5500

5245GSE

Each 31,50 44,80 51,60 63,70 66,90 70,40 73,40

Useful opening

mm

800

1000

Depth

mm 120

120

Rod section

mm 27x13 27x13

Tightening force

N 6000 6000

5245GSE

Each 85,20 94,30

For snap-on clamps see Art. 429 GT-V.

vuoto

UNIVERSALSTEELBARCLAMPS,QUICK LOCKING

5245GV

Prod. SCU - Orig. Synchro - Lock

Totally in forged and hardened steel, with profiled bar.

Ratchet-type clamping device, double release (lever and button) for an easier upper and lower

bracketing. Safe location of the device for highest finger protection. Rapid screw clamp closing

and opening with little effort.

Highest tightenig even in case of vibrations.

Useful opening

mm

300

500

600

Depth

mm 120

120

120

Rod section

mm 25x12 25x12 25x12

5245GV

Each 47,60 57,40 59,60

Product running out of stock

vuoto

UNIVERSALSTEELBARCLAMPS,QUICK LOCKING

UNIVERSAL IRON BAR CLAMPS

5245GZ

Prod. SCU

Flat rod in hardened steel, side knurled.

Malleable cast iron arms. Wooden handle.

Caps in synthetic material protect clamping surface.

Useful opening

mm

100

150

200

250

300

400

500

Depth

mm 50

50

80

80

80

80

80

Rod section

mm 15x5 15x5 22x6 22x6 22x6 22x6 22x6

5245GZ

Each 8,30

8,48 12,70 13,10 13,60 14,60 15,50

vuoto

UNIVERSAL IRONBARCLAMPS

5246G

Forged and hardened bar, profiled and side knurled for highest strength.

Ribbed arms in high resistance cast iron GTW 40. Wooden handle.

Caps in syntheric material protect work surface.

Type

400L

Useful opening

mm 400

Depth

mm 120

Rod section

mm 29x9

5246G

Each 26,40

Product running out of stock

vuoto

UNIVERSAL IRONBARCLAMPS
