UNIVERSAL STEEL BAR CLAMPS
12
5245GM
Prod. SCU
Product description as Art. 5245G
Slider grip and turned plate (except size 160mm).
Useful opening
mm
160
200
250
300
400
500
600
Depth
mm 80
100
120
140
120
120
120
Rod section
mm 16x7,5 19,5x9,5 22x10,5 25x12 25x12 25x12 25x12
Tightening force
N 2500 4000 5500 6500 7500 7500 7500
5245GM
Each 22,30 28,90 34,60 44,20 49,90 53,80 57,60
Useful opening
mm
800
1000 1250 1500
Depth
mm 120
120
120
120
Rod section
mm 27x13 27x13 27x13 27x13
Tightening force
N 8500 8500 8500 8500
5245GM
Each 71,00 80,70 104,00 116,00
vuoto
UNIVERSALSTEELBARCLAMPS
5245GME
Orig. Kanca
In forged and hardened steel, profiled bar.
Quick adjusting tightening device with clamp and mobile interchangeable clamping surface.
Tested at very high clamping pressure.
Totally galvanized, burnished clamp screws.
Sliding grip.
Reinforced model.
Throat 140mm. Bar cross section 30x15mm. Reachable pressure with 150mm opening: approx.
15000 N (1500 Kg) equivalent to 50 Nm torque value.
Useful opening
mm
200
250
300
400
500
600
800
Weight
Kg
2,5
2,8
3
3,4
3,7
4,1
4,7
5245GME
Each 46,80 48,90 50,90 55,10 59,60 63,70 72,40
Useful opening
mm
1000 1200
Weight
Kg
5,2
5,7
5245GME
Each 80,70 85,10
vuoto
UNIVERSALSTEELBARCLAMPS
5245GP
Prod. SCU
In forged and hardened steel, profiled bar.Quick adjusting tightening device with rolled hardened
screw.
Interchangeable mobile clamping surface.
Reinforced model. Throat: 120mm. Bar cross section 27x13mm. Reachable pressure with
150mm opening: approx. 8500 N (850 kg).
Useful opening
mm
200
250
300
400
500
600
800
Weight
Kg 2,00
2,11
2,24
2,45
2,70
2,96
3,5
5245GP
Each 58,90 61,50 63,50 68,40 73,10 78,00 85,80
Useful opening
mm
1000
Weight
Kg
3,9
5245GP
Each 96,10
vuoto
UNIVERSALSTEELBARCLAMPS
5245GR
In forged and hardened steel, profiled bar.
Quick adjusting tightening device with rolled hardened screw provided with hexagon to be
operated aslo with torque wrenches.
Interchangeable mobile clamping surface.
Reinforced model. Bar cross section 30x15mm. Reachable pressure with 150mm opening:
approx. 12000 N (1200 kg) equivalent to 40Nm torque value.
Useful opening
mm
300
400
500
600
800
1000 1250
Depth
mm 140
120
140
120
140
120
120
Weight
Kg 3,00
3,20
3,70
3,90
4,60
5,10
6,00
5245GR
Each 76,80 82,70 91,10 95,30 110,00 120,00 138,00
Useful opening
mm
1500
Depth
mm 120
Weight
Kg 6,60
5245GR
Each 154,00
vuoto
