UNIVERSAL STEEL BAR CLAMPS
12
UNIVERSAL STEEL BAR CLAMPS
5244GA
Orig. Kanca
Excellent clamping performance, max stiffness.
Flat bar in hardened steel, side knurled. Arms in forged steel.
Wooden handle. Throat 120mm. Bar cross section 35x11mm. Reachable pressure with 150mm
opening: approx. 15000 N (1500 Kg) equivalent to 50 Nm torque value.
Useful opening
mm
200
250
300
400
500
600
800
5244GA
Each 31,00 32,10 33,30 35,60 37,90 40,10 44,70
Useful opening
mm
1000 1200 1500 2000
5244GA
Each 49,30 53,80 60,70 72,10
vuoto
UNIVERSALSTEELBARCLAMPS
5244GE
Product description as Art. 5244GA
Sliding grip. Throat 120mm. Bar cross section 35x11mm. Reachable pressure with 150mm
opening: approx. 15000 N (1500 Kg) equivalent to 50 Nm torque value.
Useful opening
mm
200
250
300
400
500
600
800
5244GE
Each 31,00 32,10 33,30 35,60 37,90 40,10 44,70
Useful opening
mm
1000 1200 1500 2000
5244GE
Each 49,30 53,80 60,70 72,10
vuoto
UNIVERSALSTEELBARCLAMPS
5245G
Prod. SCU
In forged hardened steel, profiled bar.
Quick adjusting tightening device with clamp and mobile clamping surface.
Tested at high clamping pressure.
Totally galvanized, burnished clamp screws.
With wooden handle.
Useful opening
mm
120
160
200
250
300
400
500
Depth
mm 60
80
100
120
140
120
120
Rod section
mm 13,5x6,5 16x7,5 19,5x9,5 22x10,5 25x12 25x12 25x12
Tightening force
N 1000 2500 4000 5500 6500 7500 7500
5245G
Each 18,50 23,10 29,30 35,90 44,50 51,90 55,80
Useful opening
mm
600
800
1000
Depth
mm 120
120
120
Rod section
mm 25x12 27x13 27x13
Tightening force
N 7500 8500 8500
5245G
Each 59,60 73,10 82,70
vuoto
UNIVERSALSTEELBARCLAMPS
5245GE
Orig. Gedore - Art. TGP
Product description as Art. 5245G
With ergonomic wooden handle, articulated, joining the advantages of a fixed wooden handle and
of a lever handle.
Useful opening
mm
300
400
800
1000 1200
Depth
mm 140
120
120
120
120
Rod section
mm 25x12 25x12 28x14 28x14 28x14
Tightening force
N 6500 7500 8500 8500 8500
5245GE
Each 46,90 48,70 67,90 78,30 87,30
Product running out of stock
