959
REVOLUTION COUNTERS
959
11
Prices in EURO - VAT not included
4438GD
4438GS
Prod. SCU
Electrical ADDITIONING system.
Quick zero-setting by means of lever. Body in die-cast aluminium, sturdy construction. Upon
reach of the preset value, a micro commuter is activated according to basic operation settings.
Digit number 5. Digit height 8mm. 1 rev. = 1 unit. Max. speed 5000 rpm.
Dimensions 130x87x57mm.
Contact range 1 A 24 V d.c.
Art.
4438GD 4438GS
Rotation
right
left
Each 416,00
416,00
vuoto
REVOLUTIONCOUNTERS
STROKE COUNTERS
4440G 1
4440G 2
4440G 3
4440G 4
Prod. SCU - Orig. IVO
Adds in one direction.
The lever automatically goes back to the starting point. Each stroke corresponds to one number.
Lever travel: min. 38°, max. 60°.
Max number of strokes: approx. 500 per min.
The lever can be adjusted in any postion of the shaft.
knob for instantaneous zerosetting. Number of digits 5.
Digits height 4.5mm. Base dimensions 29x60mm.
Art.
4440G 1 4440G 2 4440G 3 4440G 4
Shaft side
right
right
left
left
Rotation
right
left
right
left
Each 87,10
87,10
87,10
87,10
vuoto
STROKECOUNTERS
4440GE 1
4440GE 2
4440GE 3
4440GE 4
Prod. SCU
Adds in one direction.
The lever automatically goes back to the starting point. Each stroke corresponds to one number.
Max number of strokes: approx. 1000 per min.
The lever can be adjusted in any postion of the shaft.
Knurled knob for instantaneous zero-setting. Body and cover in synthetic material.
Digit number 6. Digit height 5mm. Dimensions 46.5x33x31mm.
Art.
4440GE 1 4440GE 2 4440GE 3 4440GE 4
Shaft side
right
right
left
left
Rotation
right
left
right
left
Each 56,50
56,50
56,50
56,50
vuoto
STROKECOUNTERS
4441GD 1
4441GD 2
4441GS 1
4441GS 2
Prod. SCU - Orig. IVO
Removable key for zerosetting.
Adds in one direction.
The lever automatically goes back to the starting point. Each stroke corresponds to one number.
Lever travel: min. 38°, max. 60°.
Max number of strokes: approx. 500 per min.
The lever can be adjusted in any postion of the shaft.
Knob for instantaneous zerosetting.
Art.
4441GD 1 4441GD 2 4441GS 1 4441GS 2
Rotation
right
right
left
left
Ciphers height
mm 4,5
7
4,5
7
No. of ciphers
6
7
6
7
Wheels Ø
mm 4
7
4
7
Base dimensions
mm 60x70
120x64
60x70
120x64
Each 134,00
186,00
134,00
186,00
vuoto
STROKECOUNTERS
4442GD 1
4442GD 2
4442GS 1
4442GS 2
Movable lever for instantaneous zerosetting.
Adds in one direction.
The lever automatically goes back to the starting point. Each stroke corresponds to one number.
Lever travel: min. 38°, max. 60°.
Max number of strokes: approx. 500 per min.
The lever can be adjusted in any postion of the shaft.
Knob for instantaneous zerosetting.
Art.
4442GD 1 4442GD 2 4442GS 1 4442GS 2
Rotation
right
right
left
left
Ciphers height
mm 4,5
7
4,5
7
No. of ciphers
5
5
5
5
Base dimensions
mm 80x48
120x64
80x48
120x64
Each 153,00
239,00
153,00
239,00
vuoto
