958
REVOLUTION COUNTERS
958
11
Prices in EURO - VAT not included
4433G
4434G
Removable key for zerosetting. 1 rev. = 1 unit.
Adds in one direction. Subtracts in the opposite direction. Right hand shaft.
Ciphers height
mm 4,5
No. of ciphers
6
Wheels Ø
mm 4
Max speed
rev/min 3000
Base dimensions
mm 60x70
4433G
Each 134,00
vuoto
Product description as Art. 4433G
Adds in both directions.
Ciphers height
mm 7
No. of ciphers
7
Wheels Ø
mm 7
Max speed
rev/min 1000
Base dimensions
mm 120x64
4434G
Each 183,00
vuoto
REVOLUTIONCOUNTERS
4435GD 1
4435GD 2
4435GS 1
4435GS 2
Adds in one direction. Subtracts in the opposite direction.
Removable lever for zerosetting. 1 rev. = 1 unit.
Maximum speed 3000 rpm.
Art.
4435GD 1 4435GD 2 4435GS 1 4435GS 2
Rotation
right
right
left
left
Ciphers height
mm 4,5
7
4,5
7
No. of ciphers
5
5
5
5
Wheels Ø
mm 4
7
4
7
Base dimensions
mm 80x48
120x64
80x48
120x64
Each 150,00
240,00
150,00
240,00
vuoto
REVOLUTIONCOUNTERS
4436GD 1
4436GD 2
4436GS 1
4436GS 2
Prod. SCU
Adds in one direction. Subtracts in the opposite direction. Zero-setting by means of lever (for Art.
4436 GD - S x 2 movable in both directions) 1 rev. = 1 unit. Body in die-cast aluminium, sturdy
construction.
Art.
4436GD 1 4436GD 2 4436GS 1 4436GS 2
Rotation
right
right
left
left
Ciphers height
mm 6
7
6
7
No. of ciphers
5
6
5
6
Wheels Ø
mm 6
8
6
8
Max speed
rev/min.
3000
500
3000
500
Base dimensions
mm 93x47x32 130x67x53 93x47x32 130x67x53
Each 126,00
198,00
126,00
198,00
vuoto
REVOLUTIONCOUNTERS
REVOLUTION COUNTERS
4437GD
4437GS
Prod. SCU - Orig. IVO
Electric SUBTRACTING system.
To preset the desired value, push the lateral lever backwards and hold it in this position. Push the
button to select the desired value. Then release the lever.
The counters subtracts from the preset value, until it reaches zero, when the electric contact
disengages the counter. The electric contact may operate a relay, an alarm, a light or the three
simultaneously, close or far.
To repeat the same value, just push the lever. The counter can be connected both on the right and
on the left.
The lever can be mounted both on the right and on the left. 1 rev. = 1 unit.
For alternate current up to V 220.
Art.
4437GD 4437GS
Rotation
right
left
Ciphers height
mm 7
7
No. of ciphers
5
5
Max speed
rev/min 6000
6000
Base dimensions
mm 142x88
142x88
Each 917,00 1.090,00
vuoto
