957
DIGITAL ELECTRONIC TACHOMETERS
957
11
Prices in EURO - VAT not included
4430GF
Professional model with double function for contact measurement or light ray telemeasuring.
direct reading on display (5 digits), casing covered with rubbery material for high protection and a
more comfortable use.
Good precision equipment (±0.02% +1 digit), user friendly for measuring without mechanic
contact.
Field of contact measurement: 1 to 99999 rev/min.
Field of telemeasuring: 1 to 99999 rev/min.
Peripheral speed (with 6" wheel) from 0.10 to 1524 m/min - from 0.40 to 5000 ft/min - from 4 to
60000 in/min.
Measurement of length (with 6" wheel) from 0 to 99999 m/ft/in.
For telemeasuring apply the supplied adhesive reflective strip on the moving part.
For contact measurements apply the provided adaptor as well as the special standard tools (2
pointers and 2 wheels for peripheral speed).
Max. light ray measuring distance: 0.60m.
Incorporated memory for recalling the latest, the max., the min. and the average reading.
Field of measurement selection: m/min, m/sec., ft/min, ft/sec.,in/min, m, ft, in, rpm.
Automatic stop after 30 sec. from the latest measurement. Indicator of discharged batteries.
Operated by 2 alkaline batteries AA. Supplied in case.
4430GF
Each 432,00
For additional reflective strips see Art. O4430 GCA.
vuoto
DIGITALELECTRONIC TACHOMETERS
4430GH 1
SPARE ACCESSORIES FOR ART. 4430 GF
Extension.
4430GH 1
Each 17,20
vuoto
DIGITALELECTRONIC TACHOMETERS
4430GH 2
6" wheel for peripheral speed.
4430GH 2
Each 44,50
vuoto
DIGITALELECTRONIC TACHOMETERS
4430GH 3
0.1m wheel for peripheral speed.
4430GH 3
Each 34,30
vuoto
DIGITALELECTRONIC TACHOMETERS
4430GH 4
Convex pointer.
4430GH 4
Each 34,30
vuoto
DIGITALELECTRONIC TACHOMETERS
4430GH 5
Tapered pointer.
4430GH 5
Each 34,30
vuoto
DIGITALELECTRONIC TACHOMETERS
REVOLUTION COUNTERS
4431G 1
4431G 2
4431G 3
4431G 4
Prod. SCU - Orig. IVO
Adds in one direction. Subtracts in the opposite direction. 1 rev. = 1 unit.
Maximum speed 2000 rpm. Knob for instantaneous zerosetting. Digits height 4.5mm. Number of
digits 5. Base surface 29x60mm.
Art.
4431G 1 4431G 2 4431G 3 4431G 4
Shaft side
right
right
left
left
Rotation
right
left
right
left
Each 82,80
88,60
88,60
88,60
vuoto
REVOLUTIONCOUNTERS
